CONTROL FREAK
Example of sending on multiple MIDI channels from one slider
How to make a slider send MIDI volume on two MIDI channels at the same time
In the example below, we're using MIDI Channels 1 & 2.
Press the [–– >] key
Turn the Data Wheel to the right (clockwise) until the display shows:
Press the [–– >] key and use the Data Wheel to select the Slider to Edit
Press the [–– >] key – leave Minimum Levl at 0
Press the [–– >] key – leave Maximum Levl at 127
Press the [–– >] key – the display will show:
Turn the Data Wheel to the left (anti-clockwise) until the display shows:
Press the [–– >] key – the display will again show:
Turn the Data Wheel one click to the right and the display will show:
Press the [–– >] key – the display will show:
Turn the Data Wheel to the right (clockwise) until the display shows:
Press the [–– >] key – the display will show:
Turn the Data Wheel one click to the left - the display will show:
At this point you have set the slider to send MIDI volume (controller #7) on MIDI Channel #1.
Continue as follows to make it also send on Channel #2.
Press the [–– >] key – the display will show:
Turn the Data Wheel to the left (anti-clockwise) until the display shows:
Press the [–– >] key – the display will again show:
Turn the Data Wheel one click to the right - the display will show:
Press the [–– >] key – the display will show:
Turn the Data Wheel to the right (clockwise) until the display shows:
Press the [–– >] key – the display will show:
Turn the Data Wheel one click to the left and the display will show:
from home position to start edit and display the edit menu options.
EDITING EXAMPLES
EDIT`SLIDER`DATA
````COMMAND
``End`of`DATA
Set`MIDI`Chan`1
````COMMAND
``End of DATA
```Controller
Controller`Numbr
0``Bank Select
7``Main Volume
Controller`Value
Data`Val`00h`0
Data`from`Slider
````COMMAND
``End`of`DATA
Set`MIDI`chan``2
````COMMAND
``End`of`DATA
```Controller
Controller Numbr
0``Bank`Select
7``Main`Volume
Controller`Value
Data`Val`00h```0
Data`from`Slider
