CONTROL FREAK

Commands

When you see the
prompt you have the option of the following commands.The table below lists all currently
available commands and their associated data bytes.As may be seen, the majority of MIDI and
Internal Commands use a command followed by one or two variables.
MIDI Command
•
End of data
Controller
F0 Begin SysEx
Note-on
Note-off
Program change
NRPN MSB only
NRPN MSB + LSB
RPN MSB only
RPN MSB + MSB
Pitchbend
Mono aftertouch
Poly aftertouch
Controller Hi/Lo
MTC Quarter frame
F2 Song position pointer
F3 Song select
•
Internal program
•
Set global MIDI channel
•
Set internal clock rate
•
Set real-time value # 1
•
Set real-time value # 2
•
Internal clock start
•
Internal clock stop
•
Internal clock continue
F6 Tune request
F8 Timing clock
FA MIDI Clock start
FB MIDI Clock continue
FC MIDI Clock stop
FE Active sensing
FF System reset
Set MIDI channel 1
Set MIDI channel 16
•
Invert data
NRPNs/RPNs Note that where MSB only and MSB + LSB are referred to in the command box below, this refers to
the Data MSB or Data MSB + LSB. Parameter MSB and LSB must always be defined and sent. For
further information see NRPNs explained on page 38.
NRPN MSB only
NRPN MSB + LSB
RPN MSB only
RPN MSB + LSB
````COMMAND`````
``End`of`DATA```
Command Parameter MSB
NRPN Cntrllr MSB
NRPN Cntrllr MSB
RPN Cntrllr MSB
RPN Cntrllr MSB
Data Byte # 1
Controller number
"See ""SysEx Explained"""
Note number
Note number
Program number
See below and
NRPN/RPNs explained
Pitchbend LSB
Aftertouch amount
Note number
Controller number
Message type/value
SPP Data LSB
Song number
Internal program number
Global MIDI channel
Internal clock rate BPM
Real-time value # 1
Real-time value # 2
Parameter LSB
NRPN Cntrllr LSB
NRPN Cntrllr LSB
RPN Cntrllr LSB
RPN Cntrllr LSB
Data Byte # 2
Controller value
Velocity
Velocity
Pitchbend MSB
Aftertouch amount
Controller value MSB/LSB
SPP Data MSB
• = internal Freak data commands
F0-FF = MIDI system data commands
All others are MIDI channel commands
Data MSB Data LSB
NRPN Data MSB
NRPN Data MSB NRPN Data LSB
RPN Data MSB
RPN Data MSB RPN Data LSB
COMMANDS
21
