THE DATA WHEEL IN PLAY MODE

What to expect from the Data Wheel in PLAY MODE
In the home position, the Data Wheel is used to scroll through the available programs.The display
will show the names of the profiles they contain.
For example:
DATA ENTRY
```Program```0``
Volumes`Ch`1`-16
```Program```6``
`GS/XG`Stuff````
Real-time Edit Each press of the [< ––] button displays a different real-time edit item.When any of these is
displayed, the operation of the Data Wheel changes to control the displayed item.
`Real-Time`Edit`
Global`MIDI`#``1
`Real-Time`Edit`
Int`Clock`120bpm
`Real-Time`Edit`
R/T`Value`#1=``0
`Real-Time`Edit`
R/T`Value`#2=``0
General When you move a slider or press a button, a value is displayed on the LCD in decimal format – this
is suffixed with a d (for decimal).
When you are in edit mode and are required to enter data values, the Freak also displays a
hexadecimal number (suffixed h) as well as its decimal equivalent.This is because values
(particularly SysEx) are often given in hexadecimal format in the manufacturer's literature.
||`Program` 62``
Vols`Ch1-8`S1Ext
6
Ext. In #2
Ext. In #1
The Data Wheel changes the Global MIDI channeL.
The Data Wheel controls the tempo of the MIDI clock
generator built into the Freak.
The Data Wheel makes changes to R/T Value #1.
The Data Wheel makes changes to R/T Value #2.
When the screen is showing the program name and
number , you may see one or two up arrows in the top
left corner. These indicate that the external inputs are
active for this program.
