CHAPTER 2: Checking Out Your Convertible Notebook

Changing modules

28
Your convertible notebook's modular bay supports different bay modules, such
as a CD, DVD, combination DVD/CD-RW, or multi-format DVD±RW drive, or
multibay battery.
To change bay modules:
If you are removing a drive, make sure that there is no disc in it.
1
Turn off your convertible notebook (do not place it in Standby or
2
Hibernate mode).
Make sure the LCD panel is in notebook mode, then close the LCD panel.
3
Disconnect your convertible notebook from the optional port replicator.
4
Turn your convertible notebook over so the bottom is facing up.
5
Remove the modular bay lock screw (if one is present), then slide and hold
6
the module bay latch. The module may move out slightly.
Modular bay lock screw
