CHAPTER 2: Checking Out Your Convertible Notebook

Connecting the dial-up modem

To reduce the risk of fire, use only No. 26
AWG or larger telecommunications line
12
Your convertible notebook has a built-in 56K modem that you can use to
Warning
connect to a standard telephone line.
cord.
To connect the modem:
Insert one end of the modem cable into the modem jack
1
side of your convertible notebook.
Insert the other end of the modem cable into a telephone wall jack. The
2
modem will not work with digital or PBX telephone lines.
Start your convertible notebook, then start your communications
3
program.
www.gateway.com
on the right
