CHAPTER 3: Maintaining and Upgrading Your Notebook

Installing the keyboard

Important
The keyboard cable is correctly oriented if
it is not twisted.
48
Lift the black keyboard connector clip, then remove the cable. Be careful
14
not to touch or damage any other components.
Keyboard connector clip
Lift the old keyboard away from the convertible notebook. The keyboard
15
is now completely detached from the convertible notebook.
To install the keyboard:
Place the new keyboard keys-down on your convertible notebook with
1
the space bar away from you.
Make sure the black keyboard connector clip is fully raised, insert the cable
2
into the connector, then lower the black connector clip to lock the
connector in place.
Rotate the keyboard toward the LCD panel until the keyboard is
3
almost face-up.
