Gateway Notebook Hardware Reference Manual page 49

www.gateway.com
Remove the four screws that secure the hard drive to the hard drive kit
15
bracket.
Screw
Screw
Remove the bracket from the old drive.
16
Insert the new drive into the bracket, label side up, so the screw holes line
17
up.
Replace the four screws that secure the bracket to the drive.
18
Slide the new hard drive kit into your convertible notebook, then replace
19
the screw that secures the hard drive kit to your convertible notebook.
Replace the hard drive bay cover, then tighten the cover screws.
20
Insert the main and optional multibay battery, then turn your convertible
21
notebook over.
Connect the power adapter, modem cable, and network cable, then turn
22
on your convertible notebook.
For instructions on installing Windows, your drivers, and your applications,
23
see the Recovering Your System chapter you printed in
Replacing the hard drive kit
Screw
Screw
Step 2.
45
