Introducing the HP ProCurve 10/100 Hubs

Front of the Hubs

Front of the Hubs
These illustrations show the Hub 24 and Hub 24M. The Hub 12 and Hub 12M
have the same physical characteristics with 12 fewer 10/100 ports.
Power
LED
Fault
Reset button
LED
Activity LED
Console Port
(Hub 12M and 24M only)
1-2
Port
LEDs
Collision LED
Clear Button
(Hub 12M and 24M only)
10/100Base-T RJ-45 ports
HP ProCurve 10/100 Hub 24
MDI/MDI-X
Button for Port 1
HP ProCurve 10/100 Hub 24M
