The controls in the ViewLog window:
No Name
1 Camera Name
2 Camera View
3 Date Tree
4 Video Event List
5 View Mode
6 Camera Select
7 Advance
8 Normal
9 Function Panel
10 Scroll Bar
11 Audio Playback
12 Playback Panel
13 Function Icons
14 Playback Speed
15 Time Display
16 Date Display
17 Exit
18 A to B Mode
Frame by Frame /
19
Real Time
Description
Indicates the given camera name.
Displays the playback video.
Displays date folders.
Displays video events within a certain date folder.
Sets screen divisions: Single, Thumbnail, Quad or Multi View.
Sets a desired camera for display.
Accesses the basic or advanced search, and reloads video event
list.
Displays the date tree and video event list.
Provides various settings for ViewLog.
Scrolls forward or backward of the playback video.
Enables audio playback.
Contains typical playback control buttons.
A highlighted icon indicates an enabled function. From left to right
are the A to B Mode, auto playing of next events, the contrast and
brightness function, the light enhancement and equalization
function, the sharpness and smoothness function, the grayscale
function, and reconnection to Remote ViewLog.
Indicates the playback speed. x 1 represents normal playback
speed.
Indicates the time of the playback video.
Indicates the date of the playback video.
Closes or minimizes the ViewLog window.
Plays repeatedly the set frames A to B.
Plays back video frame by frame or on real time.
Screen Overview
