1.1 GV-2004, 2008
The GV-2004 and GV-2008, as four-in-one combo cards, include the features of previous
GV-Video Capture Card (recording of up to 16 video channels), GV-DSP Card (real-time
display), GV-A16 Card (recording of up to 16 audio channels), and GV-Hybrid DVR Card
(hardware compression). This economic device not only provides a single-card solution
but also saves the PCI slots.

Minimum System Requirements

OS Windows 2000 / Windows XP / Windows Server 2003
CPU GV-2004
GV-2008
GV-2008 x 2
RAM GV-2004
GV-2008
GV-2008 x 2
HDD GV-2004
GV-2008
GV-2008 x 2
VGA ATI Radeon 9550 or above (Recommended)
DirectX 9.0 or above
Note:
1. Currently GV-Video Capture Cards are not compatible with VIA-series and ATI-
series chipset motherboards.
2. To install two GV-2008 Cards, ensure the PC power supply is 400 Watts or above.

Packing List

1. GV-2004 or GV-2008 Card x 1
2. 1-4 D-Type Video and Audio Cable x 1
3. 5-8 D-Type Video and Audio Cable x 1
(only supplied with the GV-2008 Card)
4. 6-Pin Cable x 1
(only supplied with the GV-2008 Card)
2
Pentium 4-2.4C GHz, 800 MHz FSB
Pentium 4-2.6C GHz, 800 MHz FSB
Pentium 4-2.8C GHz, 800 MHz FSB
2 x 256 MB Dual DDR400 SDRAM
2 x 512 MB Dual DDR400 SDRAM
2 x 1G Dual DDR400 SDRAM
120 GB or above
250 GB or above
500 GB or above
5. Hardware Watchdog Jumper Wire x1
6. Software CD x 1
7. Feature Guide x 1
8. Installation Guide x 1
