Connections (DVI Type)
•
Connect the DVI video and audio cables to the GV-Combo Card.
•
Connect the DVI TV Out cable to the TV monitor if needed.
1-16 DVI Video Cable
2
DVI TV Out Cable
2
1-16 DVI Audio Cable
3
Figure 1-8 GV-Combo Card (DVI Type) connections
Video Capture Cards
1
TV Monitor
GV-Combo Card
1
13
