GeoVision Surveillance system Installation Manual page 11

1.2 GV-1120, 1240, 1480
GV-1120, GV-1240 and GV-1480 are the three-in-one combo cards, providing one
single card solution for 16 video / audio recording, real-time display and TV-out display.
To meet different needs, there are three types of GV-Combo cards: D-Type, DVI Type
and PCI-E.
Minimum System Requirements
OS Windows 2000 / Windows XP / Windows Server 2003
GV-1120
CPU
GV-1240
GV-1480
RAM 2 x 256 MB Dual DDR400 SDRAM
GV-1120
HDD
GV-1240
GV-1480
VGA ATI Radeon 9550 or above (Recommended)
DirectX 9.0 or above
Note:
1. For recording resolution of 640 x 480 or above, Pentium 4 processor with Hyper
Threading is required.
2. Currently GV-Video Capture Cards are not compatible with VIA-series and ATI-
series chipset motherboards.
Packing List (D-Type and PCI-E)
1. GV-1120/1240/1480 Combo Card x 1
2. Audio Extension Card x 1
3. 1-8 D-Type Video Cable x 1
4. 9-16 D-Type Video Cable x 1
5. 1-8 D-Type Audio Cable x 1
8
Pentium 4-2.4C GHz, 800 MHz FSB
Pentium 4-2.6C GHz, 800 MHz FSB
Pentium 4-2.8C GHz, 800 MHz FSB
80 GB
120 GB
250 GB
6. 9-16 D-Type Audio Cable x 1
7. Hardware Watchdog Jumper Wire x 1
8. Software CD x 1
9. Feature Guide x 1
10. Installation Guide x1
