Connections
Use the supplied Ribbon Cable to connect the GV-DSP Card to the GV-Video Capture
Card as illustrated below.
GV Video Capture Card
TV Monitor
44
Figure 2-7 GV-DSP Card connections
40-Pin
2
Ribbon Cable
1
GV-DSP Card
