Key Defi nitions
Remote Transmitter: Transmits the radio signal to the Receiver Remote Transmitter
Collar. It is waterproof.
Transmitter Indicator Light: Indicates that a button is pressed
Transmitter Antenna
and also serves as a low-battery indicator.
Transmitter
Intensity Dial: Provides multiple levels of Stimulation so you can
Indicator
match the correction to your pet's temperament.
Light
Intensity Dial
Upper Button: This button is factory-set to deliver a Negative
Tone only.
Lower Button: This button is factory-set to deliver Continuous
Side Button
Stimulation set by the Intensity Dial.
Lower Button
Side Button: This button is factory-set to deliver a Positive Tone
only.
Upper Button
Charging Jack: For connecting the charger. Although the Remote
Transmitter is waterproof without the charger cover, keep the cover
Charging Jack
in place when not charging to keep debris out of the opening.
(with cover)
