Summary of Contents for Petsafe Sport Dog Trainer
- Page 1 Sport Dog Trainer Owner’s Guide dresseur SportDog Guide d’emploi Amaestrador SportDog Guía para el dueño...
- Page 2 II. Sport Dog Trainer Quick Guide The Sport Dog Trainer is simple and easy to use. Follow these 4 easy steps. Refer to the Table of Contents for a detailed discussion explaining each of these steps.
- Page 3 III. Set-up and Operation 1. Identifying the Components/Features The Sport Dog Trainer kit contains the following components and features: A. Receiver w/Collar B. Transmitter C. Holster D. Test Light E. Range F. Battery Life A. Receiver w/Collar Receiver LED Collar...
- Page 4 It is a small bolt with an o-ring that screws into the antenna mount. It also can be used to keep dirt from getting in the antenna mount. B. Transmitter Stimulation Stimulation Transmitter LED Buttons Buttons Sport Dog Trainer Sport Dog Retriever Trainer ST-T100 ST-T120...
- Page 5 The remote radio transmitter has been ergonomically designed for the ultimate in comfort and feel. It is water resistant and has the following features: • Variable Stimulation Buttons You control the level of stimulation with the stimulation buttons. Each one is color coded and varies in intensity. Refer to "Using the System" (Page 9) for more details.
- Page 6 However, conditions such as weather, terrain, and other environmental factors can affect and thus reduce the range. To get the maximum range out of your Sport Dog Trainer, hold the transmitter in a vertical position above your head. Also, make sure that the antenna is located on the right side of the dog and is as upright as possible.
- Page 7 Figure 1 B. Inserting the Batteries in the Transmitter • The Sport Dog Transmitter requires two (2) 9 volt alkaline batteries. To insert the batteries, follow the instructions listed below: • Open the battery door by loosening the two screws in the lower back panel of the transmitter handle.
- Page 8 C. Mounting the Antenna on the Transmitter Screw the shorter antenna into the antenna mount located on top of the transmitter. The antenna is to be hand tight- ened until the black o-ring is snug against the antenna mount. Refer to Figure 4 for proper installation.
- Page 9 F. Mounting the Antenna Clip on the Collar The Following steps below display how to place the antenna clip on the collar. Step 1: Placing the clip Figure 7 Clip housing on the Collar housing Place the clip housing on the inside of the collar as shown in Figure 7.
-
Page 10: Using The System
3. Using the System A. Testing the System With an activated receiver collar, the Sport Dog Trainer can be tested to verify it is functioning properly. We recommend that you test your system, before beginning any training, to ensure that you get the desired results from your Sport Dog Trainer. - Page 11 (See page 10). B. Placing the Receiver Collar on Your Dog • Before placing the Sport Dog Trainer on your dog, be sure to wash your dog’s neck and collar’s probes with antibacterial soap. Do this at least once a week to prevent irritation.
- Page 12 There are four ranges of intensity levels that can be changed by adjusting two switches located in the receiver. They vary from low to very high. Your Sport Dog Trainer is factory set at the low intensity level. When adjusting the switches, make sure you have a small, sharp object.
- Page 13 The diagrams below show the switch configurations for each intensity level. The "on" position reflects the switch being flipped towards the battery compartment. The "off" position reflects the switch being flipped towards the components located in the receiver. Switch 6 Switch 7 (off) (off)
- Page 14 Trainer can be adjusted to one of sixteen (16) User Identification Codes. This code must be the same in both the transmitter and receiver in order for the Sport Dog Trainer to function properly. Receiver switches #1 through #4 are used to set the User Identification Code.
- Page 15 LED is depends on whether or not the receiver has a low battery. You can use your Sport Dog Trainer with multiple dogs with different intensity levels with one Single Dog Transmitter. Here’s how: For example, set each of the three receivers to a particular intensity level that is appropriate for each dog.
- Page 16 • User Identification Codes Matching in Both the Receiver and Transmitter The User Identification Codes must match in both the receiver and transmitter. If they do not, the receiver collar will not function at all. If the User Identification Codes do not match, please refer to "Interference from Other Trainers"...
- Page 17 While working with one particular dog, be sure to turn off the receiver collars on the other dogs. • To check the operation of the Sport Dog Trainer – Press the "Test/Tone" button located on the transmitter (see Page 10).
-
Page 18: Service And Warranty
• Patent pending and other patents applied for. 6.Service and Warranty Radio Systems certifies this Sport Dog Trainer to operate under Part 95 of FCC regulations. Unauthorized modifications to the equipment could result in not meeting specifications and violating FCC regulations.
