Led Diagnostics - Altronix AL842ULADA Installation Manual

AL800ADA - Power Supply Board
Terminal Legend Function/Description
L, G, N Connect 120VAC to these terminals: L to hot, N to neutral.
- DC + 24VDC @ 8 amp in alarm non-power limited output.
Form "C" dry contacts indicate the loss of AC, with AC present terminals marked [NO and C]
AC FAIL
are open, [NC and C] are closed. When loss of AC occurs terminals marked [NO and C] are
NO, C, NC
closed, [NC and C] are open.
Form "C" dry contacts used to instantaneously signal the loss AC to local annunciation devices,
AC LOCAL
with AC present terminals marked [NO and C] are open, [NC and C] are closed. When loss of AC
NC, NO, C
occurs terminals marked [NO and C] are closed, [NC and C] are open.
Form "C" dry contacts indicate low battery voltage or loss of battery voltage. Under normal
BAT FAIL
conditions terminals marked [NO and C] are open, [NC and C] are closed. During a trouble
NO, C, NC
condition terminals marked [NO and C] are closed, and [NC and C] are open (Fig. 2, pg. 7).
+ BAT - Stand-by battery input (leads provided) (Fig. 2, pg. 7).
• AC Fail condition will report approximately 30 seconds after loss of AC. To delay report for 2.5 to 3 hours cut
jumper AC DELAY on the Power Supply Board (AC trouble output delay option). If this mode is selected the Power
Supply Board must be reset by removing all power to it for 30 seconds.
• Low battery condition will report at approximately 21VDC.
• Battery presence detection will report within 180 seconds after battery remains undetected (missing or removed).
A restored battery will report within 30 seconds.
AL800ADA - Power Supply Board
Red (DC) Green (AC) Power Supply Status
ON ON
ON OFF
OFF ON
OFF OFF
AL842LGK - Logic Board
LED OFF
ON Normal
ON Normal
OFF Normal
OFF Normal
Input 1 Normal
Input 2 Normal
Fault Normal
* Indicates existing trouble condition. When a trouble condition (open, short or ground) occurs on a specific output, the
corresponding red output LED, [OUT1-OUT4] will blink. The corresponding green input LED will blink as well.
** Indicates trouble condition memory. When a trouble condition restores, the units red output LEDs [OUT1-OUT4]
will blink with a shorter and distinctly different duration. The green input LEDs will be off (normal condition).
To reset the memory depress the reset button located on the AL842LGK logic board (Fig. 2c, pg. 7).
The LED(s) will extinguish.
Note: When indicating circuits have restored, trouble memory reset is not required for normal operation.
- 6 -
Terminal Identification Table:
*Power Board Parameter Specifications:

LED Diagnostics:

Normal operating condition.
Loss of AC, Stand-by battery supplying power.
No DC output.
Loss of AC. Discharged or no stand-by battery. No DC output.
ON
Alarm Condition
Alarm Condition
Alarm Condition
Alarm Condition
Alarm Condition
Alarm Condition
Alarm Condition
BLINK (LONG)*
Trouble Condition
Trouble Condition
Trouble Condition
Trouble Condition
Trouble Condition
Trouble Condition
---
BLINK (SHORT)**
Trouble Condition Memory
Trouble Condition Memory
Trouble Condition Memory
Trouble Condition Memory
---
---
---
AL842ULADA
