Altronix AL842ULADA Installation Manual page 12

1.25"
(31.75mm)
1.5"
(38.1mm)
8.5"
(215.9mm)
18.0"
(457.2mm)
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056
web site: www.altronix.com, e-mail: info@altronix.com, Lifetime Warranty, Made in U.S.A.
IIAL842ULADA
- 12 -
Enclosure Dimensions
18" x 14.5" x 4.625" (457.2mm x 368.3mm x 117.48mm)
1.5"
(38.1mm)
4.5"
(114.3mm)
1.0"
(25.4mm)
1.0"
(25.4mm)
1.0"
(25.4mm)
1.0"
(25.4mm)
2.75" 4.5"
(69.85mm) (114.3mm)
(H x W x D approximate)
14.5"
(368.3mm)
2.5" 2.5"
(63.5mm) (63.5mm)
14.5"
(368.3mm)
4.5" 2.75"
(114.3mm) (69.85mm)
14.5"
(368.3mm)
I04M
:
1.5"
(38.1mm)
1.5"
(38.1mm)
1.0"
(25.4mm)
18.0"
(457.2mm)
1.0"
(25.4mm)
1.5"
(38.1mm)
1.25"
(31.75mm)
1.5"
(38.1mm)
2.5"
(63.5mm)
6.0"
(152.4mm)
18.0"
(457.2mm)
MEMBER
AL842ULADA
