Instruction Manual
MODEL: HD-88
8x8 HDMI Matrix Switcher
HDMI Matrix Switcher Series
Thank you for purchasing the HD-88 HDMI Matrix Switcher. You will fi nd this unit easy to install and highly reliable
but it is essential that you read this manual thoroughly before attempting to use 8x8 HDMI Matrix switcher.
Part No.: ENCL005688NB000
Advertisement
Table of Contents
Related Manuals for A-Neuvideo HD-88
Summary of Contents for A-Neuvideo HD-88
- Page 1 HDMI Matrix Switcher Series Thank you for purchasing the HD-88 HDMI Matrix Switcher. You will fi nd this unit easy to install and highly reliable but it is essential that you read this manual thoroughly before attempting to use 8x8 HDMI Matrix switcher.
-
Page 2: Safety Information
SAFETY INFORMATION Save the carton and packing material even if the equipment has arrived in good condition. Should you ever need to ship the unit, use only the original factory packing. Read all documentation before operating your equipment. Retain all documentation for future reference. Follow all instructions printed on unit chassis for proper operation. -
Page 3: Table Of Contents
INTRODUCTION The HD-88 is high-performance 8x8 matrix routing switcher for HDMI signals. This switcher supports data rates up to 6.75 Gbps, enabling 1080p HDMI formats and UXGA/WUXGA/DVI resolution to any HD display. High Defi nition Digital signals can be selected and distributed to any 8 outputs simultaneously. -
Page 4: Features And Specifications
FEATURES & SPECIFICATIONS FEATURES 1. Support 8x HDMI digital source devices matrix switched to 8x HDMI devices. 2. HDMI digital video with embedded audio, DVI format and HDCP compliant 3. Seven (7) function key control and worldwide EDID modes for HDTV resolutions. 4. -
Page 5: Edid Function
EDID FUNCTION EDID function for HDMI Matrix Switcher To view the current EDID status: Step 1. Press EDID button; the button will flash blue and the display will show the current EDID Status. Step 2. Press EDID button to exit. To change the current EDID status: Method 1 Step 1. -
Page 6: Front Panel
FRONT PANEL FRONT PANEL POWER SWITCH The power switch turns the unit on and off. The LED will illuminate red to indicate that the switcher is ON and is receiving power. The Switcher will remember that last state during a power cycle. When power is removed and resorted, the last confi... -
Page 7: Front Panel - Control Functions
FRONT PANEL FRONT PANEL FUNCTION KEY - OFF Disables (mute) video to selected channels. Either destinations. - Press OFF button followed by any Destination channel. - Press 1 thru 8 output destination. The display will show ” 0 “ for the selected channel indicating no video selected. FUNCTION KEY - RECALL ( preview ) The system will show previously stored presets, up to a total of 16. -
Page 8: Rear Panel
REAR PANEL REAR PANEL DC POWER INLET Power Jack: The Switcher is fi tted with a DC power plug input connector. ᴓ DC Jack - Inner OD 2.1mm (+ ) Ensure that the used is of an approved type and is of suffi cient ᴓ... -
Page 9: Typical Application
6. HDMI (HDCP Compliant) 3. HDMI (HDCP Compliant) 7. HDMI (HDCP Compliant) 4. HDMI (HDCP Compliant) 8. HDMI (HDCP Compliant) DC POWER INPUT: SUPPORT DC12V POWER INPUT HD-88 SUPPORT EIGHT HDMI INPUTS TO EIGHT HDMI MATRIX OUTPUTS SUPPORT IR EXTENDER & RS-232 CONTROLS. -
Page 10: Remote Control
REMOTE CONTROL Before making any connections to the switcher. Observe the following: > Ensure the mains voltage supply matches the label on the > Connect all audio video sources and destination equipment supplied plug-pack (+/- 10%) > Power up all source and destination audio-visual sources >... -
Page 11: Ir Extender
IR EXTENDER REAR PANEL IR EXTENDER PORT *** When you plug the External IR extender into the switcher, the front panel IR receiver remains active. *** IR EXTENDER PACKAGE :... -
Page 12: Rs-232 Serial Interface
RS-232 SERIAL INTERFACE RS-232 SERIAL INTERFACE CONNECT a PC or CONTROL SYSTEM. VERSION COMPATIBLE V1.0 & V1.5 RS-232 SERIAL INTERFACE RS-232 Defi nition -------- Not used Transmitter Receiver -------- Not used Ground -------- Not used -------- Not used -------- Not used -------- Not used RS-232... -
Page 13: Rs-232 Serial Commands
RS-232 SERIAL COMMANDS MORE STUFF Note: Turning the unit System Power 011 via RS-232 will extinguish the LED channel display leaving only the Power SW~ LED on. The Video and Audio outputs will also mute. While the unit is turned 011 by RS-232 it will continue to accept and act upon switching commands. -
Page 14: Limited Warranty
LIMITED WARRANTY LIMITED WARRANTY The warrants this product against defects in materials and workman ship for a period of 1 year from the date of purchase. Should this product, Prove defective within this warranty period, will repair this product without charge, to whatever extent it shall deem necessary to restore said product to proper operation condition.
