FX: pre-programmed effects

The table below lists the pre-programmed dynamic effects (macros) that can be controlled using channels
23 - 27 in 16-bit Extended Mode.
You select effects on channels 23 and 25 by sending the values listed in the table. You can adjust effect
parameters such as speed and intensity on channels 24 and 26, and you can adjust synchronization of
effects across different fixtures on channel 27.
Applicable when running MAC Quantum Profile firmware version 1.0.0.
DMX
Effect
value
1 Gobo X-fade
2 Bad Stepper
3-7 Reserved
8 Tick Tick Tick
9 Tick Tock
10 Wave
11 Step
12 Pulse
13 Double Strobe
14 Triple Strobe
15 Up, Down, Flash
16 Up, Flash, Down, Flash
17 Random Levels
18-20 Reserved
21 Electric Arc
22 Atomic Lightning
23 Thunderstorm
24 Welding
25-29 Reserved
30 Stop Motion*
31 Movie Flicker*
32 Cross Chase*
33 Random Dimmers*
34 Shakey Dimmers*
35 Center Out Chase*
36 Negative Pulse*
37 Positive Pulse*
38-49 Reserved
50 Rainbow Wave
51 Rainbow Step
52 Rainbow Pulse
53 RGB Wave
54 RGB Step
55 RGB Pulse
56 CMY Wave
57 CMY Step
58 CMY Pulse
59 Mix to White Wave
60 Mix to White Step
*Animotion effect
DMX
Effect
value
61 Mix to White Pulse
62 Random Mix Wave
63 Random Mix Step
64 Random Mix Pulse
65 Random Subtle Wave
66 Red White Blue Fade
67 Red White Blue Snaps
68-69 Reserved
70 Full Bumps
71 All Bumps
72 Split Bumps
73 Random Split Bumps
74 Color Shaker
75 Fire
76 Water
77 Ice
78 Hot and Cold
79 Warm and Fuzzy
80 Iris Wave
81 Iris Step
82 Iris Pulse
83 Zoom Wave
84 Zoom Step
85 Zoom Pulse
86 Random Size Wave
87 Random Size Step
88-89 Reserved
90 Pin to Flood
91 Pounce
92 Splash
93-109 Reserved
110 Three Beams
111 Small Spidey
112 Circle Cuts
113 Mill Cuts
114 Dots in Motion
115 Lots of Dots
116 Moonflower
117 Starlight
Table 2: FX in the MAC Quantum Profile
DMX protocol
DMX
Effect
value
118 Windows
119 Three Ring Circus
120 Flying Bananas
121 Beamage
122 Spider Twist
123 Milling Around
124 Flicker Dots
125 Tick Tock Cone
126 Flap Flap
127 Nervous Dots
128 Chasing Dots
129 Counter Flaps
130-159 Reserved
160 Fire
161 Reserved
162 Water
163 Reserved
164 Vertical Scratches
165 Horizontal Scratches
166 Box Animation
167 Chasing Worms
168 Spidermotion
169 Curvy Field
170 Big Balls
171 Veins
172 Yellow Veins
173 Wavy Bones
174 Blubber
175-209 Reserved
210 Zoom Fade
211 Fade Spin Zoom
212 Gobo Twist
213 Expand Twist
214 Expand Twist Out
215-219 Reserved
220 Circle Square
221 Circle Open
222 Line By Line
223-255 Reserved
