DMX protocol

Applicable when running MAC Quantum Profile firmware version 1.0.0.
Basic 16-bit
16-bit Extended
Mode Mode
1 1
2 2
3
3 4
4 5
5 6
6 7
20
DMX Value Function
Strobe/shutter effect
0 - 19 Shutter closed
20 - 49 Shutter open
Strobe, slow → fast
50 - 200
201 - 210 Shutter open
Random strobe, slow → fast
211 - 255
Dimmer fade (MSB)
0 - 255
Closed → open
Dimmer fade (LSB)
0 - 65535
Closed → open
Cyan
0 → 100%
0 - 255
Magenta
0 → 100%
0 - 255
Yellow
0 → 100%
0 - 255
Color wheel
Continuous Scroll (split colors possible)
Open
0
Open → Slot 1
1 - 14
Slot 1 (Blue)
15
Slot 1 → Slot 2
16 - 29
Slot 2 (Green)
30
Slot 2 → Slot 3
31 - 44
Slot 3 (CTC 3200 K)
45
Slot 3 → Slot 4
46 - 59
Slot 4 (Magenta)
60
Slot 4 → Slot 5
61 - 74
Slot 5 (Congo Blue)
75
Slot 5 → Slot 6
76 - 89
Slot 6 (Red)
90
Slot 6 → Open
91 - 104
Open
105 - 160
Stepped Scroll (snap to full color positions)
Slot 1 (Blue)
161 - 163
Slot 2 (Green)
164 - 166
Slot 3 (CTC 3200 K)
167 - 169
Slot 4 (Magenta)
170 - 172
Slot 5 (Congo Blue)
173 - 175
Slot 6 (Red)
176 - 178
Open
179 - 192
Continuous Rotation
CW, Fast → Slow
193 - 214
Stop (This will stop the color wheel wherever it is at the time)
215 - 221
CCW, Slow → Fast
222 - 243
Random color
Fast
244 - 247
Medium
248 - 251
Slow
252 - 255
Table 1: DMX Protocol
MAC Quantum Profile User Guide
Fade Default
type value
Snap 30
Fade 0
Fade 0
Fade 0
Fade 0
Fade 0
Snap 0
