- Page 1 www.martin.com...
- Page 2 The Woodroffe Gobo Collection Thank you for choosing the Woodroffe Gobo Collection from Martin for the MAC 2000 Profile. This leaflet contains instructions for changing the gobos in your existing fixture. On the reverse side of this page, the correct standard layout of the gobo set is shown in detail.
- Page 3 Special Note: The structured glass gobo ‘Limbo’, originally installed in the MAC 2000 Profile in position 5 on wheel 1, remains in the fixture in the same position under the new name ‘Crystal’. The structured glass gobo ‘Limbo Doughnut’ in position 1 on wheel 2 needs to be removed.
- Page 4 Procedure for replacing a gobo To replace a rotating gobo in the MAC 2000 Profile II: 1. Disconnect the fixture from power and allow it to cool. 2. Lock the head in the upside-down position, as indicated by the text on the rear panel, and remove the bottom cover (see Fig.
- Page 5 3. Remove the gobo retention spring from the gobo holder and drop the gobo out of the holder. 4. Insert the new gobo in the holder. Important: if one side of a gobo is more reflective, this side must face towards the lamp, and the darker side must face away from the lamp Warning: To minimize the risk of gobo overheating and damage, turn the...
- Page 6 5. Insert the spring with the narrow end against the gobo.(see Fig.C) To identify the narrow end, press the spring flat: the narrow end is on the inside. Push the wider end of the spring in under the lip of the holder. 6.
- Page 7 The Woodroffe collection as installed in the MAC 2000 Profile II Wheel 1...
- Page 8 The Woodroffe collection as installed in the MAC 2000 Profile II Wheel 2...
- Page 9 The Woodroffe collection as installed in the MAC 2000 Profile II Wheel 3...
- Page 10 www.martin.com...
