Software installation

Software updates are installed in the MAC 2000 Profile using a Martin MP-2 Uploader or a LightJockey 4064 DMX
interface card. The procedure is found in the MP-2 user manual and the Martin Software Uploader online help file.
Requirements
The following are required in order to install software.
• The MAC 2000 Profile update file, available for download from the User Support Area of the Martin web site
(http://www.martin.dk).
• The Martin Software Uploader program, version 4.0 or later, available for download from the User Support Area of the
Martin web site.
• A Martin MP-2 Uploader connected to a Windows 95/98/ME/2000/XP PC, or a LightJockey DMX Interface card.
Preventing software updates on a MAC 2000 Profile II
Software updates are enabled by default, but on a MAC 2000 Profile II you can disable this by setting the Write jumper
(see MAC 2000 Profile II PCB on page 39) to disable.
Boot sector jumper
If the normal upload procedure does not work, or if the software update notes call for a boot sector update, move the
boot sector jumper on the printed circuit board to the BOOT position before uploading software. The procedure differs
slightly between the MAC 2000 Profile and the MAC 2000 Profile II.
S
E T T I N G T H E B O O T S E C T O R J U M P E R
1 Disconnect the fixture from power.
2 Remove the top screws from the ends of the front side panel and tilt the
panel down to expose the main circuit board.
3 Using the appropriate diagram in Circuit board connections on page 38 or
the label inside the base, locate the BOOT jumper. This is PL16 on a MAC
2000 Profile II, or PL103 on an original MAC 2000 Profile). Move the jumper
to the "BOOT" position.
4 Perform a boot mode upload. When the upload is complete, disconnect the
fixture from power and move the jumper back to the locked or normal
position.
