Remote Antenna Receiver

The Remote Antenna Receiver consists of two pieces – the mounting plate and
the Antenna housing. The Remote Antenna Receiver is installed similar to a
wireless access point. Best locations are high on the wall, facing into the room
in which the microphones are located. Each Remote Antenna Receiver
supports one Base DSP Unit. If more than one Base DSP Unit is installed for a
room, e.g. more than eight microphones are required, several Remote Antenna
Receivers will be installed in this room. It is best to install the receivers on the
same wall facing into the room, spaced at least 12 inches (30 cm).
The Remote Antenna Receiver contains several antennas to provide the best
transmission and reception of the radio signal to and from the microphones.
Routing channels
