Remote Antenna Receiver
The Remote Antenna Receiver consists of two pieces – the mounting plate and
the Antenna housing. The Remote Antenna Receiver is installed similar to a
wireless access point. Best locations are high on the wall or under the ceiling,
facing into the room in which the microphones are located. Each Remote
Antenna Receiver supports one Base DSP Unit. If more than one Base DSP
Unit is installed for a room, e.g. more than eight microphones are required,
several Remote Antenna Receivers will be installed in this room. It is best to
install the receivers on the same wall facing into the room, spaced at least 12
inches (30 cm).
The Remote Antenna Receiver contains several antennas to provide the best
transmission and reception of the radio signal to and from the microphones.
Routing channels
19
