3. Specification
Frequency Preparation.....
Carrier Frequency Range
S/N Ratio...............................
T.H.D.......................................
Display...................................
Display Contents................
Controls..................................
Audio Output Level...........
AF Output Impedance......
Squelch...................................
Operation Voltage...............
Output Connector................
Dimension(m/m)..................
Channel..................................
4. Parts Identification & Accessories
1. Power On/Off switch
2. Channel Selector ( Down button )
3. Channel Selector ( Up button )
4. Set button
5. LED Display
6. Volume control
7. DC socket for connection of main unit
8. AF output, Ø6.3mm phone jack socket
(AF UNBAL)
9. AF output, XLR socket (AF BAL)
10. Antenna input socket
11. Antenna
Optional Accessories
12. DR-900 Dual Rack Adaptor
13. RP-900 Panel Cover
14. GC-80/GC-100 Guitar Cable
15. GC-80L/GC-100L Guitar Cable
PLL Synthesized Control
502~960MHz
> 105dB
<0.6%@1KHz
LED
AF Level, Channel
Power On/Off, Channel, Audio Level
-12dB
600Ω
Pilot Tone & Noise Mute
12-18 VDC, 600 mA
1 XLR Balanced Socket
1 Ø6.3mm unbalanced phone jack
211mm (W)* 40mm (H)* 125mm (D)
16 selectable channels
7
AF OUTPUT
BALANCED
AF OUTPUT
DCV INPUT
UNBAL .
12-18V/500mA
ANT. 2
12
13
11
Freq. Range:
Serial No.:
ANT. 1
14
15
