TG-10STX Stationary Transmitter

1. Important Cautions

.Make all connections before plugging the unit into an AC power outlet.
.Do not leave the devices in a place with high temperature or
high humility.
.Do not handle the power cord with wet hands.
.Keep the devices away from fire and heat sources.

2. Introduction

The TG-10STX is an UHF PLL stantionary transmitter with 16 selectable
channels. It works with all JTS 16 channel systems with channel indication
0,1,2......9,A,B.......F.
Together with directional antenna UDA-49P, antenna booster UB-900 the
TG-10STX can provide stronger signal for larger coverage.

3. Specification

Carrier Frequency Range.........
RF Output Power........................
Nominal Frequency Deviation
(modulation)
Audio Input Impedance.............
Nominal Input Level...................
Maximal Input Level..................
LED Display..................................
Audio Input Connector..............
Output Monitor Connector.......
Loop Out Connector....................
Operation Voltage........................
Dimension(m/m)...........................
Channel...........................................
502~960MHz
Hi / Low
±40KHz
20KΩ
-20 dBV
0 dBV
AF Level, Channel
2 x Balanced XLR / Ø6.3mm Combo input
Ø6.3mm monitor input
1 x Ø3.5mm phone Socket
2 x Ø6.3mm Balanced Loop Out Socket
12-18 VDC, 600 mA
210mm (W)* 44mm (H)* 239mm (D)
16 selectable channels
