SHB212 PICMG1.3 Half-Size SBC User's Manual
3.6
Memory Map
Address
00000000-
System board
0009FFFF
000A0000-
Intel® Graphics Media Accelerator 3150
000BFFFF
000A0000-
PCI Bus
000BFFFF
000C0000-
System board
000CFFFF
000D0000-
PCI Bus
000DFFFF
000E0000-
System board
000FFFFF
00100000-
System board
7F6FFFFF
7F700000
PCI Bus
DFFFFFFF
D0000000-
Intel® Graphics Media Accelerator 3150
DFFFFFFF
F0000000
PCI Bus
FED8FFFF
FE880000–
Intel® Graphics Media Accelerator 3150
FEA7FFFF
FEAC0000–
Intel® 82567V-3 Gigabit Network Connection
FEADFFFF
FEAF8000–
Microsoft UAA Bus Driver for High Definition Audio
FEAFBFFF
FEAFF400–
Intel® ICH8 Family USB2 Enhanced Host Controller
FEAFFBFF
36
Devices
HARDWARE DESCRIPTION
