3.1
Microprocessors
The SHB212 Series supports Intel® Atom™ processor N455/D425/
D525, which make your system operated under Windows XP/Vista and
Windows 7 environments. The system performance depends on the
microprocessor.
3.2
BIOS
The SHB212 Series uses American Megatrends BIOS with 16Mbit SPI
Flash, DMI, Plug and Play.
3.3
System Memory
The SHB212 Series industrial CPU card supports one 204-pin
unbuffered DDR3 SO-DIMM socket for a maximum memory of 4GB
DDR3 SDRAM (N455 is only for DDR3-667, maximum memory
capacity up to 2GB).
HARDWARE DESCRIPTION
SHB212 PICMG1.3 Half-Size SBC User's Manual
HARDWARE DESCRIPTION
CHAPTER 3
31
