2.3.8 CompactFlash

Function

3.3V type CompactFlash

(Default)

5V type Compact Flash

The board supports 3.3V or 5V type LCD displays.

Function

3.3V type LVDS LCD support

(Default)

5V type LVDS LCD support

JUMPERS AND CONNECTORS

SHB212 PICMG1.3 Half-Size SBC User's Manual

Type Selection (JP11)

Jumper Setting

support

Jumper Setting
