3.1.4 Integrated Peripherals

VIA OnChip IDE Device
VIA OnChip PCI Device
Super IO Device
Init Display First
↑↓→← Move
The settings on the screen are for reference only. Your version may not be iden-
tical to this one.
VIA OnChip IDE Device
Move the cursor to this field and press <Enter>. The following fields
will appear.
OnChip Primary IDE and OnChip Secondary IDE
These fields allow you to enable or disable the primary and sec-
ondary IDE controller. The default is Enabled. Select Disabled if
you want to add a different hard drive controller.
IDE Prefetch Mode`
This allows data and addresses to be stored in the internal buffer
of the chip, thus reducing access time. Enable this field to achieve
better performance.
IDE Primary Master/Slave PIO and IDE Secondary Master/Slave PIO
PIO means Programmed Input/Output. Rather than have the
BIOS issue a series of commands to effect a transfer to or from
the disk drive, PIO allows the BIOS to tell the controller what it
wants and then let the controller and the CPU perform the
complete task by themselves. Your system supports five modes, 0
Phoenix - AwardBIOS CMOS Setup Utility
