2.5.7 Game/MIDI Port
Game Port
The Game/MIDI port is identical to that of a standard PC game
adapter or game I/O port. Connect an analog joystick to the 15-pin
D-sub connector (Gold). This port works well with any application
that is compatible with the standard PC joystick.
BIOS Setting
Configure the game port in the Integrated Peripherals submenu
("Super IO Device" section) of the BIOS. Refer to chapter 3 for
more information.
Hardware Installation
10
8 2
7 9
1
2
