H
J
2
1
L
M
2
1
P
manual line
feed button
Auto Line Feed System
line cutter

How to trim and edge

K
N
1

Manual line feed

How the automatic line feed works (H)
1. When initially switching on the trimmer, a small length
of line is fed out.
2. A 'clattering' noise will be heard when the nylon line hits
the line cutter. DO NOT BE ALARMED this is quite nor-
mal. After approximately 5 seconds the line will be cut
to the correct length and the noise will reduce as the
motor reaches full speed.
• Make sure the motor is up to full speed before trimming
or edging.
3. If the noise of the nylon line being cut cannot be heard,
more line will need to be fed out.
4. To feed more line, it is first necessary to to allow the
motor to stop completely, then re-start, allowing the
motor to reach full speed.
5. Repeat step 4. until you hear the line hitting against the
cutter. (Do not repeat this procedure more than 6 times)
6. If problems are experienced with the automatic line
feed refer to Fault Finding Chart.
• WARNING
• The use of eye protection is recommended.
Do not lean over the trimmer whilst trimming or edging,
objects may be thrown by the cutting line.
Do not allow cutting head to rest on the ground.
Do not overload your trimmer.
Overloading can be avoided by making sure the motor
speed does not drop unduly.
• BEFORE USE
Make sure that both lines are fed out.
• Make sure motor is up to full speed before trimming or
edging.
How to trim
• The switchbox is provided with a lock-off button (J1) to
prevent accidental starting.
1. To start, press lock-off button (J1), squeeze the switch
lever (J2), release lock-off button.
1. Hold as illustrated in Fig J.
2. To start, squeeze the switch lever.
3. Cut with nylon line at an angle using the tip. (K).
4. Swing trimmer in and out of the cutting area taking
small cuts (L)
5. Line is fed out automatically every time the trimmer
head stops rotating and returns to operating speed.
• Extra line can be fed out manually as described in
Manual line feed
6. To stop your trimmer release the switch lever.
How to edge
1. To convert to edging mode, press button (M1) and twist
head (M2). An audible "click" will confirm that the head
is locked.
2. Hold as illustrated in Fig J.
3. To start, squeeze the switch lever.
4. Rest edger on wheel for extra stability and line up the
edge of the lawn with the two indicators on the guard
(N1). Edge in direction indicated in Fig N.
5. To stop your trimmer release the switch lever.
6. To return to trimming mode, press button and twist
head back the opposite way. An audible "click" will con-
firm that the head is locked.
To manually feed the nylon line (P)
1. If required line can be fed out manually.
2. To operate, press and release manual line feed button,
whilst gently pulling on the line until it reaches the line
cutter.
3. If the line extends past the line cutter, too much line has
been fed out.
4. If too much line is fed out, remove the spool cap and
click spool anti-clockwise until the line is at the desired
length.
