Cutting Head; Maintenance - Flymo CONTOUR POWER PLUS CORDLESS Original Instructions Manual

To remove spool cap
1. Press and hold in the two cap release latches. (R).
2. Pull cap away from the spoolholder. (R).
When refitting the spool cap
1. Keep all areas of the cap and spoolholder clean.
Failure to do so may prevent the cap being securely
located in the spoolholder.
2. Replace the cap, pressing firmly DOWN towards
the spoolholder to ensure cap is fully located.
3. Check that the cap is correctly fitted by trying to re-
move it without depressing the two latches.
To replace nylon line.
For your convenience it is recommended you buy
spool and line complete. Nylon line only is also avail-
able. Both are available from Flymo Approved stock-
ists.
To fit spool and line complete:
1. Remove old spool.
2. Place new spool into spoolholder with cut out area of
the spool in line with eyelet as shown in figure S.
3. Release line from cleat and feed line through eyelet (S).
• Ensure spool is fully located by gently rotating it dur-
ing fitment, whilst keeping the spoolholder steady.
4. Refit the cap.
To fit nylon line only:
• Remember ! Your product is designed to use only
nylon line with a maximum diameter of 1.5mm. Use
only genuine Flymo nylon line.
1. Take approximately 10 metres of line. Insert 15mm
of line into the hole in the spool (T) and wind line in
the direction of the arrows on the top of the spool.
Leave approximately 100mm of line unwound and
place into cleat (T1).
2. Care should be taken to ensure that the line is
neatly coiled on the spool. Failure to do so will im-
pair the efficiency of the automatic line feed.
3. Then fit spool as described in 'To fit spool and line
complete', section above.
Always return the product to its normal operating posi-
tion before switching on.
• WARNING
Cutting head continues to rotate after the trimmer
has been switched off. Keep fingers and hands
clear of the line cutter on leading edge of guard.
Caring
After you have finished using your product follow the
procedure below:
AVOID ACCIDENTAL STARTING. KEEP FEET AWAY
FROM THE SWITCH LEVER WHEN: CLEANING
AROUND THE INSIDE OF THE SAFETY GUARD,
REMOVING OR REFITTING SPOOL CAP , MANU-
ALLY FEEDING OR REPLACING NYLON LINE.
1. Disconnect from the mains electricity supply.
2. Never clean your trimmer with water, cleaning flu-
ids, or solvents, just remove debris with a suitable
tool, a soft brush or dry cloth.
3. Using a soft brush, clean around the inside of the
safety guard, the cutting head (Fig V) and the
motor housing air vents. (Fig W)
4. Remove the wheel by pressing one of the buttons.
Clean the wheel and groove on trimmer head with
a soft brush (X & Y).
5. Attach wheel as described in Wheel Assembly.
6. Inspect the trimmer carefully, especially the parts
of the cutting head.
7. If your trimmer is damaged in any way contact your
local approved service centre.
• Never use a damaged trimmer.
8. Store in a cool, dry place and out of reach of children.

Cutting Head

R
Spoolholder
S
T

Maintenance

V
X
Spool
Cut out area
of spool
T1
W
Y
Cap
Cap release
latch
Eyelet
Eyelet
Cleat
