Flymo CONTOUR POWER PLUS CORDLESS Original Instructions Manual page 4

B1
C1
D
Fitting the Wall Bracket and Charging the Battery
F
3
G
1
Assembly Instructions cont'
B2
C2
E
1
2
3
2
1
4
• The battery should be
charged for 24 hours be-
fore use.
• Re-charge your cordless
trimmer immediately after
every use for the full 24
hour charging period.
• The cordless trimmer can
be left connected to the
charger permanently, with
the charger switched on,
without fear of overcharging.
Safety Guard Assembly (B1) & (B2)
1. Locate the safety guard over the cutting head. Ensure
the nylon line is fed through the hole in the safety guard
as illustrated in fig B1.
2. Push into location and turn safety guard in the direction
illustrated in Fig B2, until a click is heard and the safety
guard is securely locked in position.
• ENSURE THE SAFETY GUARD IS SECURELY IN
PLACE BY ATTEMPTING TO TWIST GUARD.
Wheel Assembly (C1) & (C2)
1. Fix the 2 halves of the wheel together as illustrated in fig C1.
2. Attach the wheel to the trimmer making sure that it is lo-
cated into the groove on the trimmer head (C2).
3. Clip the wheel together on the other side, making sure
it is secure.
4. The wheel should turn freely.
Steady Handle Assembly (D)
1. Depress the two buttons on the sides of the switch handle.
2. Locate the steady handle over the buttons and release
the buttons.
3. Adjust the steady handle to the most comfortable oper-
ating position by depressing the buttons and moving
the handle.
Height Adjustment (E)
1. Turn height adjuster (E1) in the direction indicated to
un-lock (E2).
2. Adjust the length of the tube to the most comfortable
operating position.
3. Turn height adjuster in the opposite direction to lock (E3).
• ENSURE THAT THE TUBE IS FULLY SECURED.
• IMPORTANT ! Switch charger off at the wall socket before
connecting or disconnecting the trimmer to the wall bracket.
1. It is recommended that the wall bracket (F2) should be
mounted on a smooth, vertical and internal wall which is
strong enough to hold the weight of the product, in a
well ventilated area between 5°C and 25°C.
2. There are 3 holes on the wall bracket. Position the wall
bracket with the two holes at the top. See Fig G.
3. Ensure that when the trimmer is attached the bottom of
the trimmer is within 4 inches (100 mm) of the ground,
this will make it easier to hang the trimmer and will also
ensure that the wall bracket is within easy reach of an
electric socket to allow the charger to be plugged in.
4. Fix wall bracket securely to the wall with the plugs and
screws provided.
5. Your cordless trimmer can now be attached to the wall
bracket for charging.
Initial Charging Procedure
1. Use the charger indoors only.
2. Ensure the charger is not exposed to moisture. Keep
the charger and the trimmer dry at all times. Keep the
charger well ventilated during charging.
3. Ensure the trimmer is correctly located into the wall
bracket (F2) and the charge connector (G1).
4. Plug the charger (F1) into a suitable household electri-
cal wall socket and switch on.
5. The red indicator lamps (F3, F4) glow continuously dur-
ing charging.
• The red indicator lamp on the product (F3) is a power
indicator and will continue to glow red even when the
battery is fully charged.
6. Full charge will be achieved in 24 hours after which the
indicator lamp on the charger (F4) will turn to green.
During charging the charger becomes warm. This is
normal and means the charger is operating correctly.
Re-Charging Your Cordless Trimmer
1. Re-charge the battery as soon as the cutting power of
your cordless trimmer begins to die and slow down.
2. Avoid running the cordless trimmer into "deep" dis-
charge, i.e. avoid flattening the battery completely.
3. Follow the procedure outlined in the Initial Charging
Procedure.
4. Charging the battery according to these instructions
should ensure maximum battery life.
• The charger will automatically keep the battery topped
up with charge during storage and will ensure that the
cordless trimmer is ready for use.
