only items suitable for user maintenance.
12. Do not insert any object into the motor area. Keep
free of debris to avoid overheating.
13. Do not incinerate or mutilate the battery. Batteries
contain hazardous chemicals. Dispose of properly.
Preparation
1. While using your product always wear eye protection,
substantial footwear and long trousers. Do not operate
the equipment when barefoot or wearing open sandals.
2. Before using the machine and after any impact, check
for signs of wear or damage and repair as necessary.
3. Inspect the area to be cut before each use. Remove
all objects such as stones, broken glass, nails, wire,
string etc, which can be thrown or become entangled
in the trimmer head.
4. Before use, inspect the area for wildlife, especially
hedgehogs.
5. Check that the cutting head, spool and cap are fitted
correctly.
Use
1. Use the trimmer only in daylight or good artificial light.
2. Avoid operating your trimmer in wet grass, where feasible.
3. Take care in wet grass, you may lose your footing.
4. On slopes, be extra careful of your footing and wear
non-slip footwear.
5. Do not walk backwards when trimming, you could
trip. Walk, never run.
6. Never operate the trimmer with damaged guards or
without guards in place.
7. Never fit metal cutting elements.
8. Keep hands and feet away from the cutting means at all
Battery Care
1. If over a period of time the battery quickly runs down
after a full 24 hour charging period, a replacement
battery is needed.
2. There will be some charge present in the battery but
to ensure maximum running time, recharge your
trimmer for 24 hours before use.
3. Permanent connection to the charger in a well venti-
lated area will automatically keep your battery fully
charged ready for use.
4. To prevent permanent battery damage, never store
in a discharged condition.
5. Contact your local approved service cen-
tre/dealer/distributor for a replacement battery and
for safe disposal of your old battery.
6. Battery
12 Volt 7 Amp/Hour
Sealed for Life
• IMPORTANT
DISPOSE OF YOUR OLD BATTERIES SAFELY
DO NOT CUT OPEN, BURN OR INCINERATE.
Battery Replacement
Should your battery need to be replaced contact your
local approved service centre or dealer who will re-
move your old battery and fit a genuine Flymo replace-
ment battery.
A1
"High Power"
No maintenance required

Assembly Instructions

A2
times and especially when switching on the motor.
9. Keep cutting head below waist level.
10. Do not lean over the trimmer guard whilst trimming or
edging - objects may be thrown by the cutting line.
11. Beware of cut-off pieces of nylon line ejected during use.
12. If you hit an object, do not use your trimmer until you
are sure that the entire trimmer is in a safe operating
condition.
13. If the trimmer starts to vibrate abnormally, check im-
mediately. Excessive vibration can cause injury.
Maintenance and storage
1. Keep all nuts, bolts and screws tight to be sure the
trimmer is in safe working condition.
2. Replace worn or damaged parts for safety.
3. Only use the replacement cutting line specified for
this product.
4. Only use replacement parts and accessories recom-
mended by Husqvarna UK Ltd..
5. After any maintenance in dealing with the cutting line,
always return the product to its normal operating po-
sition before switching on.
6. To avoid the risk of injury keep fingers and hands
clear of the line cutter on the leading edge of the guard.
7. Clean unit with a dry cloth. Never use metal objects
to clean the unit.
8. Inspect and maintain the trimmer regularly. Any re-
pairs must be carried out by an authorised repairer.
9. Store the product in a cool, dry place and out of
reach of children. Do not store the product outdoors.
10. Allow the product to cool for at least 30 minutes be-
fore storing.
Battery
To remove the Battery
1. Remove the bolt and nut (as shown in
Pic) and remove the battery cover.
2. Detach the leads from the old battery.
3. Attach the replacement battery
IMPORTANT
The red lead should always be
connected to the red terminal (+)
on the battery. The other lead
should always be connected to the
black terminal (-) on the battery.
4. Refit the battery cover and secure with the bolt and nut.
Bench Top Re-charging
The wall bracket can also be used as a "bench top"
stand for re-charging your cordless trimmer.
Winter Storage
1. Fully charge for 24 hours before winter storage.
2. If you are unable to leave your cordless trimmer on
permanent charge, re-charge the battery every 3 to
4 months for a full 24 hour charging period to top up
the battery charge during winter storage.
3. Avoid extended storage without re-charge.
4. Store in a cool dry place.
For further information on Battery replacement contact
Husqvarna UK Ltd. Customer Service direct:-
Telephone: 0844 844 4558 UK 1800 882 350 ROI
Fax: 01325 302530
Assembly of Switch Handle to Tube (A1)
• Ensure that the internal cable is not twisted.
1. Insert the tube into the switch handle.
2. Push until it clicks into position.
• ENSURE THAT THE TUBE IS FULLY LOCATED BY AT-
TEMPTING TO REMOVE IT.
Assembly of Trimmer Head to Tube (A2)
• Ensure that the internal cable is not twisted.
1. Insert the tube into the trimmer head.
2. Push until it clicks into position.
• ENSURE THAT THE TUBE IS FULLY LOCATED BY AT-
TEMPTING TO REMOVE IT.
