CanyCom CMX222 Operator's Manual page 82

5323M-0510-080E
5323M-0510-090E
5321M-0510-060E
5321M-0510-070E
Maintenance
3.
Rubber Boot
4.
5.
6.
Socket
7.
8.
Tail Lamp
1.
2.
Lens
3.
4.
5.
Light Bulb
-73-
Remove rubber boot.
Remove socket.
Replace with a new light bulb.
Put rubber boot back in place.
Install light unit back in place.
Install front cover back in place.
Remove upper rear cover.
Remove 2 screws to remove lens.
Replace with a new light bulb.
Install lens back in place.
Install upper rear cover back in place.
5
