Save & Exit Setup; Exit Without Saving - EPOX EP-6VBA2 User Manual

EP-6VBA2
Note: To support LBA or LARGE mode of HDDs, there must be some software
involved. All the software is located in the Award HDD Service Routine
(INT 13h). It may fail to access a HDD with LBA (LARGE) mode selected
if you are running under an Operating System which replaces the whole
INT 13h.
UNIX operating systems do not support either LBA or LARGE and must utilize
the Standard mode. UNIX can support drives larger than 528MB.
4-11 Save & Exit Setup
The "SAVE & EXIT SETUP" option will bring you back to the boot up procedure
with all the changes you just recorded in the CMOS RAM

4-12 Exit Without Saving

The "EXIT WITHOUT SAVING" option will bring you back to normal boot up
procedure without saving any data into CMOS RAM.
All old data in the CMOS will not be destroyed.
BIOS
.
Page 4-25
