EPOX EP-6VBA2 User Manual page 16

Features
• EP-6VBA2 utilizes a Lithium battery which provides environmental
protection and longer battery life.
• Supports the (4) Universal Serial Bus (USB) Ports. The onboard
VT82C686A chip provides the means for connecting PC peripherals such
as; keyboards, joysticks, telephones, and modems.
• Built-in ATX 20-pin power supply connector.
• Software power-down when using Windows
• Supports ring-in feature (remote power-on through external modem,
allows system to be turned on remotely).
• Resume by Alarm - Allows your system to turn on at a preselected time.
• Power Loss Recovery - In the event of a power outtage your system will
automatically turn itself back on without user intervention.
• Supports CPU Hardware sleep and SMM (System Management Mode).
• Supports Keyboard power ON function (KBPO).
• Built-in WOL (Wake-up On Lan) Connector.
• Built-in WOM (Wake-up On Modem) Connector.
• Built-in AC97 PCI Audio.
Page 2-2
EP-6VBA2
®
95/98.
