DTC Flipper SHORT Dual-Sided Printing Module Removal

Complete Short Flipper Assembly
D930010-04 DTC1250e Dual side
D930010-06 DTC4250e & 4500e Short Flipper
DTC4250e
If the Dual-Sided Printing Module needs to be
removed for any Printer Replacement procedures
or to remove the covers follow this procedure.
Step Procedure
1
Caution: Turn OFF the Printer and unplug the power cord from the Printer.
November 2013
.
DTC1000Me-1250e-4250e-4500e Card Printer Service Manual PLT-01543 rev 1.0
DTC1250e Dual
Tools needed: T10 Torx screwdriver
Estimated Repair Time: 15 minutes
Preparation:
Important: This procedure can only be performed by
authorized service personnel.
DTC1250e DTC4250e
Top Cover only
D930192-03 D930192-01
Flipper Front Door only
D930194-01 D930194-01
DTC4500e
D930192-01
D930194-01
