WARNING FIRE HAZARD
NEV E R exhaust air or terminate duct work into spaces between walls, crawl spaces, ceiling,attics or garages. All exhaust must
be ducted to the outside.
Use single wall rigid Metal ductwork only.
Fasten all connections with sheet metal screws and tape all joints w/ certi ed Silver Tape or DuctTape.
Some Ducting Options:
side wall cap
w/ gravity damper
So it or crawl space
Roof Pitch w/
Flashing & Cap
External Blower
So it or crawl space
6
www.zephyronline.com
External
Blower
