WWW.ZEPHYRONLINE.COM
Typhoon
AK2100CS, B, W
AK2136CS, B, W
AK2142CS
AK2148CS
C C
TM
Airflow Control Technology
Hurricane
AK2500CS, B, W
AK2536CS, B, W
C C
TM
Airflow Control Technology
Cyclone
AK6500CS, B, BS, W
AK6536CS, B, BS, W
AK6542CS
EN Use, Care, and Installation Guide
FR Guide d'utilisation, d'entretien et d'installation
JAN21.0101
Advertisement
Table of Contents
Related Manuals for Zephyr Typhoon AK2136CS
Summary of Contents for Zephyr Typhoon AK2136CS
- Page 1 WWW.ZEPHYRONLINE.COM Typhoon AK2100CS, B, W AK2136CS, B, W AK2142CS AK2148CS Airflow Control Technology Hurricane AK2500CS, B, W AK2536CS, B, W Airflow Control Technology Cyclone AK6500CS, B, BS, W AK6536CS, B, BS, W AK6542CS EN Use, Care, and Installation Guide FR Guide d’utilisation, d’entretien et d’installation JAN21.0101...
- Page 2 C O R E T Y P H O O N , H U R R I C A N E & C Y C LO N E U N D E R - C A B I N E T Typhoon, Hurricane, &...
-
Page 3: Table Of Contents
Contents ZEPHYRONLINE.COM Page Safety Information ................4-6 Types of Safety Warnings ..............4 General Safety ..................4-5 Operation ................... 6 Electrical Requirements ..............6 List of Materials ................... 7 Installation Instructions ..............8-20 Ducting Calculation Sheet ..............8 Mounting Height, Clearance, & Ducting ........... 9-10 Ducting Options ................. -
Page 4: Safety Information
C O R E Safety Information T Y P H O O N , H U R R I C A N E & C Y C LO N E U N D E R - C A B I N E T READ AND SAVE THESE INSTRUCTIONS Your safety and the safety of others are very important. - Page 5 Safety Information ZEPHYRONLINE.COM READ AND SAVE THESE INSTRUCTIONS WARNING WARNING WARNING - TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, WARNING - TO REDUCE THE RISK OF INJURY TO PERSONS OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: IN THE EVENT OF A RANGE TOP GREASE FIRE, OBSERVE THE FOLLOWINGa: Installation work and electrical wiring must be done by qualified person(s) in accordance with all applicable codes and...
-
Page 6: Operation
C O R E Safety Information T Y P H O O N , H U R R I C A N E & C Y C LO N E U N D E R - C A B I N E T READ AND SAVE THESE INSTRUCTIONS Operation Always leave safety grilles and filters in place. -
Page 7: List Of Materials
List of Materials ZEPHYRONLINE.COM Parts Supplied Quantity Part Hood Safety grilles LumiLight LED Hardware package 7” Round transition adapter (AK21, AK25) 3-1/4”x10” rectangular 6” Round transition adapter (AK65) starting collar (pre-installed on top of hood) 3-1/4”x10” rectangular cover plate 3-1/4”x10” rectangular vertical (pre-installed on back of hood) transition adapter #6 x 1”... -
Page 8: Installation Instructions
C O R E Installation Instructions T Y P H O O N , H U R R I C A N E & C Y C LO N E U N D E R - C A B I N E T Ducting Calculation Sheet Equivalent number Equivalent number... -
Page 9: Mounting Height, Clearance, & Ducting
Installation Instructions ZEPHYRONLINE.COM Mounting Height, Clearance, & Ducting i n . ” m ” m 3 6 ” Typhoon, Hurricane, & Cyclone Use, Care, and Installation Guide... - Page 10 C O R E Installation Instructions T Y P H O O N , H U R R I C A N E & C Y C LO N E U N D E R - C A B I N E T Mounting Height, Clearance, &...
-
Page 11: Ducting Options
Installation Instructions ZEPHYRONLINE.COM Ducting Options WARNING Fire Hazard: NEVER exhaust air or terminate ductwork into spaces between walls, crawl spaces, ceilings, attics, or garages. All exhaust must be ducted to the outside, unless using the recirculating option. Use single wall rigid metal ductwork only. Fasten all connections with sheet metal screws and tape all joints w/ certified Silver Tape or Duct Tape. -
Page 12: Ak21 Hood Specifications
C O R E Installation Instructions T Y P H O O N , H U R R I C A N E & C Y C LO N E U N D E R - C A B I N E T (30”) 28 ”, (36”) 34”... -
Page 13: Ak25 Hood Specifications
Installation Instructions ZEPHYRONLINE.COM (30”) 27 ” (36”) 33 ” ” ” elec k /o (30”) 29 ”, (36”) 35 ” ” FRONT BACK ” ” ” SIDE Typhoon, Hurricane, & Cyclone Use, Care, and Installation Guide... -
Page 14: Ak65 Hood Specifications
C O R E Installation Instructions T Y P H O O N , H U R R I C A N E & C Y C LO N E U N D E R - C A B I N E T (30”) 27 ”, (36”) 33 ”, (42”) 39... -
Page 15: Electrical Supply
Installation Instructions ZEPHYRONLINE.COM Electrical Supply WARNING Electrical wiring must be done by qualified person(s) in accordance with all applicable codes and standards. Turn off electrical power at service entrance before wiring. For personal safety, remove house fuse or open circuit breaker before beginning installation. Do not use extension cord or adapter plug with this appliance. -
Page 16: Rectangular Vertical Ducting Preparation
C O R E Installation Instructions T Y P H O O N , H U R R I C A N E & C Y C LO N E U N D E R - C A B I N E T Rectangular Vertical Ducting Preparation By default the Typhoon and Hurricane are pre-configured for 7”... -
Page 17: Rectangular Horizontal Ducting Preparation
Installation Instructions ZEPHYRONLINE.COM Rectangular Horizontal Ducting Preparation By default the Typhoon and Hurricane are pre-configured for 7” round vertical ducting. By default the Cyclone is pre-configured for 6” round vertical ducting. 1. Using a Philips-head screwdriver remove the screws and round vertical transition adapter from the top of the hood. - Page 18 C O R E Installation Instructions T Y P H O O N , H U R R I C A N E & C Y C LO N E U N D E R - C A B I N E T 4.
-
Page 19: Mounting The Hood
Installation Instructions ZEPHYRONLINE.COM Mounting the Hood FIG. B Typhoon, Hurricane, & Cyclone Use, Care, and Installation Guide... - Page 20 C O R E Installation Instructions T Y P H O O N , H U R R I C A N E & C Y C LO N E U N D E R - C A B I N E T Mounting the Hood Hood is designed for installation under a kitchen cabinet (FIG.
-
Page 21: Features & Controls
Features & Controls ZEPHYRONLINE.COM AK21 Capacitive Touch Typhoon, Hurricane, & Cyclone Use, Care, and Installation Guide... -
Page 22: Ak25 Electronic Touch
C O R E Features & Controls T Y P H O O N , H U R R I C A N E & C Y C LO N E U N D E R - C A B I N E T AK25 Electronic Touch Typhoon, Hurricane, &... -
Page 23: Ak65 Mechanical Slide
Features & Controls ZEPHYRONLINE.COM AK65 Mechanical Slide Blower On/Off Speed Selection Lights Off/Dim/Bright BLOWER ON/OFF/SPEED SELECTION 0 is off, 1 is low speed, 2 is medium speed and 3 is high speed. LIGHTS OFF/DIM/BRIGHT 0 is off, 1 is dim, and 2 is bright. * ACT (Airflow Control Technology) is not available on AK65 Typhoon, Hurricane, &... -
Page 24: Maintenance
Hood & Filter Cleaning Self-cleaning Feature Zephyr Typhoon, Hurricane and Cyclone hoods are filter-less with a self cleaning feature. The centrifugal blower system automatically liquefies cooking residue in its internal housing. All hoods are equipped with dishwasher safe residue cups to collect cooking residue during the self cleaning function. - Page 25 Maintenance ZEPHYRONLINE.COM Hood & Filter Cleaning Cleaning Instructions AK21 1. Power on blowers at Speed 1. AK25 AK65 2. With nozzle on “spray”, squirt grease cutting detergent onto blower wheel blades 30 - 35 times. Repeat for each blower. Leave blower on for 10 minutes. Detergent will collect in the residue cups.
- Page 26 C O R E Maintenance T Y P H O O N , H U R R I C A N E & C Y C LO N E U N D E R - C A B I N E T Hood &...
-
Page 27: Lumilight Led
Maintenance ZEPHYRONLINE.COM LumiLight LED In the unlikely event that your LumiLight LED or LED light strip fails, please contact Zephyr to order replacement parts. See the list of parts and accessories page for part numbers and contact information. LED Removal (FIG. C): 1. -
Page 28: Act™ Conversion
Some local codes limit the maximum amount of CFM a range hood can move. ACT™ allows you to control the maximum blower CFM of select Zephyr Ventilation range hoods without the need for expensive make up air kits. ACT™ enables the installer to easily set the maximum blower speed to one of two most commonly specified CFM levels;... -
Page 29: Enabling Act
ACT™ Conversion ZEPHYRONLINE.COM Enabling ACT™ To enable ACT™: 1. Before hood installation, gain access to PC board by following the steps shown on FIG. D. 2. Change plastic jumper positioning as shown in FIG. E to set the desired maximum blower CFM. 3. - Page 30 C O R E ACT™ Conversion T Y P H O O N , H U R R I C A N E & C Y C LO N E U N D E R - C A B I N E T Accessing PC Board Instructions NOTE: Take care when removing PC board as there are many wires connected to the board.
-
Page 31: Wiring Diagram
Wiring Diagram ZEPHYRONLINE.COM AK21C WIRING DIAGRAM AK25C WIRING DIAGRAM AK65C WIRING DIAGRAM WHITE WHITE GREY GREY BROWN BROWN BLUE BLUE MOTOR MOTOR BLACK GREY YELLOW YELLOW BODY AC 120V MOTOR MOTOR BODY Typhoon, Hurricane, & Cyclone Use, Care, and Installation Guide... -
Page 32: Troubleshooting
C O R E Troubleshooting T Y P H O O N , H U R R I C A N E & C Y C LO N E U N D E R - C A B I N E T Possible Problem Possible Cause Solutions... -
Page 33: List Of Parts & Accessories
List of Parts & Accessories ZEPHYRONLINE.COM Description Part Number Replacement Parts LumiLight LED, 6W (AK21 & AK25) Z0B0047 LumiLight LED, 6W (AK65) Z0B0049 Residue Cup (AK21) 56160003 Residue Cup (AK25 & AK65) 56160007 Safety Grille Stainless (AK21) 50220024 Safety Grille Black (AK21) 50220025 Safety Grille White (AK21) 50220026... -
Page 34: Notes
C O R E Notes T Y P H O O N , H U R R I C A N E & C Y C LO N E U N D E R - C A B I N E T Typhoon, Hurricane, &... -
Page 35: Limited Warranty
Zephyr Ventilation, LLC (referred to herein as “we” or “us”) warrants to the original consumer purchaser (referred to herein as “you” or “your”) of Zephyr products (the “Products”) that such Products will be free from defects in materials or workmanship as follows:... -
Page 36: Product Registration
Ensures warranty coverage should you need service. Ownership verification for insurance purposes. Notification of product changes or recalls. Zephyr Ventilation | 2277 Harbor Bay Pkwy. | Alameda, CA 94502 | 1.888.880.8368 Typhoon, Hurricane, & Cyclone Use, Care, and Installation Guide...
