There are two icons that depict the state of the NETRS232_x ports and devices:
Icon:
Device available on the network.
Icon with red X:
Device not available on the network.
Instruction Manual
Icon with green square:
Under "My Computer, " this icon
means the port is available.
Under "My IP Extender
Neighborhood, " this icon means the
port is activated locally.
Icon with red square:
Under "My Computer, " this icon
means the port is not available.
Under "My IP Extender
Neighborhood, " this icon means the
port is not activated locally.
