- Page 1 NETRS232 One/Two/Four Port Quick Installation Guide Rev. C02...
-
Page 2: Getting Started
NETRS232.The NETRS232 places the serial data in a TCP/IP wrapper and sends it out its Ethernet port. Data moving the other direction, from the Ethernet side of the NETRS232 to the serial device, undergoes the same process in reverse. -
Page 3: Hardware Setup
Network status is indicated by two LEDs on the RJ-45 connector.The left (yellow) LED indicates network activity. It is on by default, turning off when network activity occurs at the NETRS232.The right (green) LED indicates a network link. It is off by default, but lights when a network link exists. -
Page 4: Software Installation
B. Configuring network settings IP-Extender Manager interface. Any NETRS232 devices that are discovered on your network are displayed in the "IP-Extenders Near Me" branch of the "My IP-Extender Network" tree. NETRS232 devices installed on your network will need unique IP addresses.These can... - Page 5 NETRS232 settings. Configuring NETRS232 network settings using a web browser To set a NETRS232's network settings using a web browser, open the browser and enter the IP address of the NETRS232 into the browser's location bar.The embedded web server running on the NETRS232 will display the opening screen of the NETRS232 configuration menu.
- Page 6 C. Activating & Deactivating NETRS232 ports NETRS232 ports that have been detected as existing on the network are not initially activated for your PC.To access a NETRS232 port it must be activated.You may wish to activate on a given computer some, all, or none of the NETRS232 ports that are available on the network.To activate a...
- Page 7 NETRS232 device, right click on that device in the left panel of the Manager and select “Remove All” . Icons depict the states of NETRS232 devices and ports as follows: Device not Device available Under “My Computer”: Under “My Computer”:...
- Page 8 This device complies with part 15 of the FCC Rules. Operation is subject to the following conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
