Specifications - Icom IC-R9500 Service Manual

SECTION 1
General
• Frequency coverage (unit: MHz)
Europe, U.K., Canada, EXP, Australia, China 0.005000–3335.000000
• Operating mode
• Number of memory channels
• Antenna connector
• Operating temperature range
• Frequency stability
• Frequency resolution
• Power supply requirement
• Power consumption
Receive
• Dimensions (projections not included)
• Weight
• ACC connector
• DATA IN connector
• Display*
• EXT-DISPLAY connector
• RS-232C connector
• VIDEO IN connector
• VIDEO OUT connector
• SPEECH OUT connector
• LINE OUT connector
• USB connector
• CI-V connector
• ANT-SEL connector
• DET OUT connector
• EXT-SP connectors
• REC REMOTE connector
• REC OUT connector
• PHONES connector
SPECIFICATION
:
USA 0.005000–821.999999, 851.000000–866.999999,
896.000000–3335.000000
France 0.0050000–29.999999, 50.200000–51.200000,
87.500000–108.000000, 144.000000–146.000000,
430.000000–440.000000, 1240.000000–1300.000000
: USB, LSB, CW, FSK, AM, FM, WFM, P25
: 1220 (1000 regular channels, 100 auto memory write
channels, 100 skip channels, 20 scan edge channels)
: Type-N 2 (antenna impedance: 50 ),
SO-239 1 (antenna impedance: 50 ),
Phono (RCA) 1 (antenna impedance: 500 )
: 0ºC to +50ºC; +32ºF to +122ºF
: Less than ±0.05 ppm
main power, [I/O], ON, 0–50
: 1 Hz
: 100 V, 120 V, 230 V, 240 V AC
:
Stand-by Less than 100 VA
Max. audio Less than 100 VA
: 424 149 340 mm; 16
: Approx. 20 kg; 44 lb
: 8-pin DIN connector
: 8-pin DIN connector
: 7-inch
: D-sub 15S
: D-sub 9-pin
: Phono (RCA)
: Phono (RCA)
: Phono (RCA)
: Phono (RCA)
: USB (Universal Serial Bus)1.1/2.0
: 2-conductor 3.5 (d) mm (
: 3-conductor 3.5 (d) mm (
: 3-conductor 3.5 (d) mm (
: 2-conductor 3.5 (d) mm (
: 3-conductor 3.5 (d) mm (
(Front and rear panels)
: 3-conductor 3.5 (d) mm (
: 3-conductor 3.5 (d) mm (
(approx. 5 min. after from turn the
º
C; 32–122
11 7
/ 5
16
TFT color LCD (800 480)
(diagonal)
1 / )
8
1
/ )
8
1 / )
8
1
/ )/8
8
1
/ ) 2
8
1
/ )
8
1 / )
8
1 - 1
º
F)
3
/ 13 / in
8 8
