Icom IC-R9500 Service Manual page 92

[RF-A UNIT]
REF ORDER
NO. NO.
J1 6510007020 TMP-J01X-V6
J2 6510007020 TMP-J01X-V6
J190 6510007020 TMP-J01X-V6
J210 6510007020 TMP-J01X-V6
J290 6510007020 TMP-J01X-V6
J500 6510007020 TMP-J01X-V6
J671 6510007020 TMP-J01X-V6
J730 6510007020 TMP-J01X-V6
J800* 6510019981 52808-1671
J900* 6510018961 B2B-PH-SM4-TB (LF) (SN)
J1310 6510007020 TMP-J01X-V6
EP401 6910002161 CASE-BM7H-LF
EP402 6910002161 CASE-BM7H-LF
EP421 6910002161 CASE-BM7H-LF
EP422 6910002161 CASE-BM7H-LF
EP441 6910002161 CASE-BM7H-LF
EP442 6910002161 CASE-BM7H-LF
EP461 6910002161 CASE-BM7H-LF
EP462 6910002161 CASE-BM7H-LF
EP481 6910002161 CASE-BM7H-LF
EP482 6910002161 CASE-BM7H-LF
MP130 6910001130 10M SHIELD CASE
MP131 8510016060 2590 HF CASE
MP132 8510015910 2590 HF COVER
MP133 8930072440 Shield sponge (BZ)
MP134 8930072440 Shield sponge (BZ)
MP401 8930065740 2590 D-EARTH SPRING
MP580 6910001130 10M SHIELD CASE
MP600 8510012400 2177 D/A CASE
MP730 8510015900 2590 M-2LO CASE
MP1250 8510012400 2177 D/A CASE
MP1251 8510012400 2177 D/A CASE
MP1311 8510015900 2590 M-2LO CASE
[RF-B UNIT]
REF ORDER
NO. NO.
J801* 6510023480 AYU1-1P-02676-120
J1201* 6510023480 AYU1-1P-02676-120
J1202* 6510023480 AYU1-1P-02676-120
J1301 6510018450 TMP-S01X-B1
J1305 6510018450 TMP-S01X-B1
J1601* 6510019981 52808-1671
J1801* 6510019981 52808-1671
J1831* 6510019971 52808-1071
J1851* 6510019971 52808-1071
MP101 8510017890 2844 RF CASE
MP201 8510017890 2844 RF CASE
MP301 8510017890 2844 RF CASE
MP401 8510017890 2844 RF CASE
MP501 8510017890 2844 RF CASE
MP601 8510017890 2844 RF CASE
MP701 8510017890 2844 RF CASE
MP801 8510017890 2844 RF CASE
MP901 8510017890 2844 RF CASE
MP1201 8510017890 2844 RF CASE
MP1202 8930014140 earth spring (D)
MP1203 8930014140 earth spring (D)
MP1205 8930065740 2590 D-EARTH SPRING
MP1251 8510017880 2844 MIX A-CASE
MP1301 8510017890 2844 RF CASE
MP1302 8510017890 2844 RF CASE
MP1305 8930017200 752 earth spring
MP1306 8930017200 752 earth spring
MP1307 8930014140 earth spring (D)
MP1601 8930059122 THERMALLY SHEET (AJ)-2
MP1602 8930070220 THERMALLY SHEET (BG)
MP1801 8930066570 FERRITE SHEET (O)
*: Refer to SECTION 7 BOARD LAYOUTS.
Screw abbreviations
DESCRIPTION
DESCRIPTION
A B0 BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
[MIX1 UNIT]
REF ORDER
QTY.
NO. NO.
1 J1* 6510019971 52808-1071
1 J101* 6510023480 AYU1-1P-02676-120
1 J301* 6510023480 AYU1-1P-02676-120
1 J302 6510007020 TMP-J01X-V6
1
1 W1 8900015660 OPC-1596
1 W2 8900015780 OPC-1634
1
1 MP101 8510017880 2844 MIX A-CASE
1 MP102 8930014140 earth spring (D)
1 MP103 8930071550 Shield sponge (BM)
MP201 8930014140 earth spring (D)
1 MP301 8510017880 2844 MIX A-CASE
1 MP302 8930014140 earth spring (D)
1 MP303 8930071550 Shield sponge (BM)
1 MP401 8510017900 2844 MIX B-CASE
1 MP402 8510017910 2844 MIX B-COVER
1 MP403 8930070450 2844 MIX B-PLATE
1 MP404 8930052091 SHIELD TAPE (F)-1
1 MP405 8930052091 SHIELD TAPE (F)-1
1 MP406 8930071870 2844 FR SHEET
1 MP410 8810007231 Setscrew (H) 3X8 ZC3
1
1
1 [MIX2 UNIT]
1
REF ORDER
1
1 NO. NO.
1
J1 6510007020 TMP-J01X-V6
1
J41 6510007020 TMP-J01X-V6
1
J101 6510007020 TMP-J01X-V6
1
J201* 6510019971 52808-1071
1
1
EP102 6910002161 CASE-BM7H-LF
MP21 8510017880 2844 MIX A-CASE
MP121 8510017880 2844 MIX A-CASE
MP201 8510017900 2844 MIX B-CASE
MP202 8510017910 2844 MIX B-COVER
MP203 8930070450 2844 MIX B-PLATE
QTY.
MP204 8930071880 2844 MIX SPONGE
MP205 8930029060 Insulation sheet (CT)
1
MP210 8810007231 Setscrew (H) 3X8 ZC3
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
6 - 9
DESCRIPTION QTY.
DESCRIPTION QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
2
