Icom IC-R9500 Service Manual page 91

[DC-DC UNIT]
REF ORDER
NO. NO.
RL101 6330001060 APQ3311
RL102 6330001060 APQ3311
J1 6510003461 B10B-EH-S (LF) (SN)
J2 6510003441 B08B-EH-S (LF) (SN)
J4 6510003441 B08B-EH-S (LF) (SN)
J7 6510014961 B2B-ZR-SM4-TF (LF) (SN)
F141* 5210001040 ICP-S1.2
F142* 5210001040 ICP-S1.2
F143* 5210001050 ICP-S0.5
F144* 5210001050 ICP-S0.5
F145* 5210001040 ICP-S1.2
F146* 5210001040 ICP-S1.2
W1 8900015610 OPC-1591
MP1 8510015720 2590 DC-DC A-CASE
MP3 8930068260 THERMALLY SHEET (AV)
MP21 8510015720 2590 DC-DC A-CASE
MP23 8930068260 THERMALLY SHEET (AV)
MP41 8510015720 2590 DC-DC A-CASE
MP43 8930068260 THERMALLY SHEET (AV)
[OSC UNIT]
REF ORDER
NO. NO.
RL10 6330001750 FTR-B4CA012Z
RL11 6330001750 FTR-B4CA012Z
J2* 6510019971 52808-1071
J71 6510007020 TMP-J01X-V6
J72 6510007020 TMP-J01X-V6
J73 6510007020 TMP-J01X-V6
[REG UNIT]
REF ORDER
NO. NO.
F1 5210000131 FGB 4A PBF
5210001030 0234002MXP
F2 5220000380 F-400-01A1
5220000390 F-400-01A2
MF1 2710000810 FD124010HB-1N7
W1 8900015620 OPC-1592
W2 8900015681 OPC-1598A
W3 8900015690 OPC-1600
W4 8900015700 OPC-1602
EP1 6910016800 PBA150F-15
EP2 6910017300 ZUG2206-11S
MP1 8510017020 2844 REG CASE
MP2 8510017090 2844 REG COVER
MP3 8930068520 2844 REG T-PLATE
MP4 8810008460 Setscrew (H) 2.6X16 NI
MP5 8810007231 Setscrew (H) 3X8 ZC3
MP6 8810009461 Screw M3X8 ZK3
MP7 8810001990 Screw PH M5X18 BS NI
MP8 8850000440 S-washer M5 NI
MP9 8830000360 Nut M5 NI
MP10 8830000211 NUT M5 BS-CD NI
MP11 8850000150 Flat washer M5 BS NI
MP12 8810009880 Screw BiH M4X8 NI
MP13 8310068790 2844 earth seal
MP14 8850001561 TOOTHED WASHER (A) M4 ZC3
MP15 8930072550 2844 PW PLATE
DESCRIPTION QTY.
DESCRIPTION QTY.
DESCRIPTION QTY.
[USA], [USA-01]
[others]
[USA], [USA-01]
[others]
[BPF UNIT]
REF ORDER
NO. NO.
1 RL1 6330001721 ATN207-K1
1 RL2 6330001721 ATN207-K1
RL21 6330001721 ATN207-K1
1 RL22 6330001721 ATN207-K1
1 RL41 6330001721 ATN207-K1
1 RL42 6330001721 ATN207-K1
1 RL61 6330001721 ATN207-K1
RL62 6330001721 ATN207-K1
1 RL81 6330001721 ATN207-K1
1 RL82 6330001721 ATN207-K1
1 RL101 6330001721 ATN207-K1
1 RL102 6330001721 ATN207-K1
1 RL121 6330001721 ATN207-K1
1 RL122 6330001721 ATN207-K1
RL141 6330001721 ATN207-K1
1 RL142 6330001721 ATN207-K1
RL181 6330001721 ATN207-K1
1 RL201 6330001721 ATN207-K1
1 RL202 6330001721 ATN207-K1
1 RL203 6330001721 ATN207-K1
1 RL204 6330001721 ATN207-K1
1 RL205 6330001721 ATN207-K1
1 RL221 6330001721 ATN207-K1
RL222 6330001721 ATN207-K1
RL241 6330001721 ATN207-K1
RL242 6330001721 ATN207-K1
RL261 6330001721 ATN207-K1
RL262 6330001721 ATN207-K1
RL281 6330001721 ATN207-K1
RL282 6330001721 ATN207-K1
1
J1* 6510020521 52808-1271
1
J11 6510007020 TMP-J01X-V6
J501 6510007020 TMP-J01X-V6
1
J502 6450001800 JPJ1044-01-010
1
1
W1 7120000470 ERDS2T0
1
MP211 8930065740 2590 D-EARTH SPRING
[ANT UNIT]
REF ORDER
NO. NO.
1
1
RL101 6330001840 ARE1009
1
RL102 6330001840 ARE1009
1
RL103 6330001840 ARE1009
RL104 6330001840 ARE1009
1
RL201 6330001840 ARE1009
RL202 6330000810 ARK115
1
RL501 6330000810 ARK115
1
1
J1 6510007020 TMP-J01X-V6
1
J2* 6510023480 AYU1-1P-02676-120
J3* 6510023480 AYU1-1P-02676-120
1
J1001* 6510019981 52808-1671
1
MP1 8510017890 2844 RF CASE
1
MP2 8510017890 2844 RF CASE
1
MP3 8930014140 earth spring (D)
1
MP4 8930014140 earth spring (D)
2
MP5 8930014140 earth spring (D)
26
MP6 8930014140 earth spring (D)
2
MP7 8930014140 earth spring (D)
1
MP8 8510018300 2844 ANT S-COVER
1
MP9 8930071550 Shield sponge (BM)
1
MP201 8510016490 2590 LOGIC B-PLATE
1
MP501 8930017190 earth spring (F)
2
MP802 8930056531 THERMALLY SHEET (AA)-1
1
1
1
1
6 - 8
DESCRIPTION QTY.
DESCRIPTION QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
