Icom IC-R9500 Service Manual page 37

NOTE: HOLD the adjustment condition (SG level and frequency etc.) until next ADJ item is displayed.
ADJUSTMENT ITEM
[V/U2-3 ATT f (2500.02MHz)]
[V/U2-3 ATT f (2550.02MHz)]
[V/U2-3 ATT f (2600.02MHz)]
[V/U2-3 ATT f (2650.02MHz)]
[V/U2-3 ATT f (2700.02MHz)]
[V/U2-3 ATT f (2750.02MHz)]
[V/U2-3 ATT f (2800.02MHz)]
[V/U2-3 ATT f (2850.02MHz)]
[V/U2-3 ATT f (2900.02MHz)]
[V/U2-3 ATT f (2950.02MHz)]
[V/U2-3 ATT f (3000.02MHz)]
[V/U2-3 ATT f (3050.02MHz)]
[V/U2-3 ATT f (3100.02MHz)]
[V/U2-3 ATT f (3150.02MHz)]
[V/U2-3 ATT f (3200.02MHz)]
[V/U2-3 ATT f (3250.02MHz)]
[V/U2-3 ATT f (3300.02MHz)]
[V/U2-3 ATT f (3334.98MHz)]
ADJUSTMENT CONDITION
• Set the SG as;
Frequency : 2500.0215 MHz
• Set the SG as;
Frequency : 2550.0215 MHz
• Set the SG as;
Frequency : 2600.0215 MHz
• Set the SG as;
Frequency : 2650.0215 MHz
• Set the SG as;
Frequency : 2700.0215 MHz
• Set the SG as;
Frequency : 2750.0215 MHz
• Set the SG as;
Frequency : 2800.0215 MHz
• Set the SG as;
Frequency : 2850.0215 MHz
• Set the SG as;
Frequency : 2900.0215 MHz
• Set the SG as;
Frequency : 2950.0215 MHz
• Set the SG as;
Frequency : 3000.0215 MHz
• Set the SG as;
Frequency : 3050.0215 MHz
• Set the SG as;
Frequency : 3100.0215 MHz
• Set the SG as;
Frequency : 3150.0215 MHz
• Set the SG as;
Frequency : 3200.0215 MHz
• Set the SG as;
Frequency : 3250.0215 MHz
• Set the SG as;
Frequency : 3300.0215 MHz
• Set the SG as;
Frequency : 3334.9815 MHz
OPERATION
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
4 - 20
VALUE
(Automatic
adjustment)
