3-5 PORT ALLOCATIONS

MAIN CPU1 (LOGIC UNIT; IC103 )
Pin
Port
number
name
1
TMS
Input port for the mode signal.
2
TCK
Input port for the clock signal.
5
TDI
Input port for the data signal.
CS0,
CS1,
6–10
CS4,
Output chip select signals.
CS5,
CS6
11
BS
Outputs bus starting signal.
12
WE0/REG Outputs D7–D0 select signal.
13
WE1
Outputs D15–D8 select signal.
14
D0
I/O port for the data signal.
19–28, D1–D10,
I/O ports for the data signals.
31–35 D11–D15
36
CAS0/DQM0 Outputs D7–D0 select signal.
37
CAS1/DQM1 Outputs D15–D8 select signal.
38
RD/WR
Outputs read/write control signal.
39
CKIO
Outputs clock signal.
49,
CS2,
Output chip select signals.
50
CS3
51–54,
A0–A3,
57–66, A4–A13, Output address signals.
69–72 A14–A17
73
CAS2/DQM2 Outputs D23–D16 select signal.
74
CAS3/DQM3 Outputs D31–D24 select signal.
75–78, D16–D19,
83–92, D20–D29, I/O ports for the data signals.
95, 96 D30, D31
99–104, A18–A23,
Output address signals.
107, 108 A24, A25
109
WE2/ICIORD Outputs D23–D16 select signal.
110
WE3/ICIOWR Outputs D31–D24 select signal.
113
SLEEP
Input port for the sleep signal.
Input port for the clock signal from the
125
PCICLK
buffer amplifier (IC106).
128
SERR
I/O port for the system error signal.
129, 130, AD31, AD30,
133–138, AD29–AD24,
I/O ports for the buffer amplifier
140–142, AD23–AD21,
(IC106) address signals.
147–151 AD20–AD16
156
DEVSEL I/O port for the device selecting signal.
164–168, AD15–AD11,
171–173, AD10–AD8, I/O ports for the buffer amplifier
177–182, AD7–AD2, (IC106) address signals.
185, 186 AD1, AD0
187–190 IRL0–IRL3 Input ports for the interrupt signals.
193
XTAL2
Output port for the crystal oscillator.
Input port for the crystal oscillator sig-
194
EXTAL2
nal.
Input port for the hardware stand-by
197
CA
signal.
Description
Pin
Port
number
name
198,
RESET,
199
TRST
200
MRESET Input port for the manual reset signal.
212
RXD
215
SCK
246
TDO
255
XTAL
256
EXTAL
3 - 6
Description
Input ports for the reset signal.
Input port for the buffer amplifier
(IC106) data signal.
I/O port for the buffer amplifier (IC106)
clock signal.
Outputs the data signal.
Output port for the crystal oscillator.
Input port for the crystal oscillator sig-
nal.
