Icom IC-R9500 Service Manual page 84

SECTION 6
[CHASSIS PARTS]
REF ORDER
NO. NO.
J1 6510000370 MR-DS
J2 6510000330 NR-DS
P1 6510003240 TMP-P01X-A1
P2 6510003240 TMP-P01X-A1
P3 6510003240 TMP-P01X-A1
P4 6510003240 TMP-P01X-A1
P7 6510003240 TMP-P01X-A1
P8 6510003240 TMP-P01X-A1
P9 6510003240 TMP-P01X-A1
P10 6510003240 TMP-P01X-A1
P11 6510003240 TMP-P01X-A1
P12 6510003240 TMP-P01X-A1
P13 6510003240 TMP-P01X-A1
P14 6510003240 TMP-P01X-A1
P15 6510003240 TMP-P01X-A1
P16 6510003240 TMP-P01X-A1
P17 6510003240 TMP-P01X-A1
P18 6510003240 TMP-P01X-A1
P19 6510003240 TMP-P01X-A1
P20 6510003240 TMP-P01X-A1
P21 6510003240 TMP-P01X-A1
P22 6510003240 TMP-P01X-A1
P25 6510003240 TMP-P01X-A1
P26 6510003240 TMP-P01X-A1
P27 6510003240 TMP-P01X-A1
P28 6510003240 TMP-P01X-A1
P29 6510003240 TMP-P01X-A1
P30 6510003240 TMP-P01X-A1
P33 6510003240 TMP-P01X-A1
P34 6510003240 TMP-P01X-A1
P35 6510003240 TMP-P01X-A1
P36 6510003240 TMP-P01X-A1
W1 9024940010 62/99/420/C31/C31
W2 9086700300 Wire 08
W3 9025900620 62/99/510/C31/C31
W4 9086700300 Wire 08
W5 8900016500 OPC-1724
W7 9025900560 62/99/330/C31/C31
W8 9086700300 Wire 08
W9 9025900540 62/99/270/C31/C31
W10 9086700300 Wire 08
W11 9025900220 62/99/390/C31/C31
W12 9086700300 Wire 08
W13 9025900110 62/99/300/C31/C31
W14 9086700300 Wire 08
W15 9025900630 62/99/570/C31/C31
W16 9086700300 Wire 08
W17 9025900600 62/99/480/C31/C31
W18 9086700300 Wire 08
W19 9025900540 62/99/270/C31/C31
W20 9086700300 Wire 08
W21 9025900290 62/99/150/C31/C31
W22 9086700300 Wire 08
W25 9028440030 62/99/630/C31/C31
W26 9086700300 Wire 08
W27 9028440060 62/99/750/C31/C31
W28 9086700300 Wire 08
W29 9025900280 62/99/600/C31/C31
W30 9086700300 Wire 08
W31 8900016290 OPC-1706
W33 9028440050 62/99/70/C31/C31
W34 9086700300 Wire 08
W35 9025900560 62/99/330/C31/C31
W36 9086700300 Wire 08
W41 8900016060 OPC-1674
W42 8900015631 OPC-1593A
W43 8900015760 OPC-1609
W44 8900015760 OPC-1609
W46 8900015670 OPC-1597
W51 8900015720 OPC-1605
W52 8900015730 OPC-1606
W53 8900015740 OPC-1607
W54 8900015750 OPC-1608
W55 8900015760 OPC-1609
W56 8900015770 OPC-1635
W57 8900016300 OPC-1704
W58 8900016280 OPC-1705
W61 8900016230 OPC-1699
W62 8900016210 OPC-1696
W63 8900016200 OPC-1695
W64 8900014730 OPC-683A
W65 8900016170 OPC-1692
W66 8900016190 OPC-1694
W67 8900016190 OPC-1694
W68 8900016180 OPC-1693
W69 8900016110 OPC-1680
W70 8900016120 OPC-1683
W71 8900014750 OPC-519A
*: Refer to SECTION 7 BOARD LAYOUTS.
Screw abbreviations A B0 BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
MECHANICAL PARTS
DESCRIPTION QTY.
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
[CHASSIS PARTS]
REF ORDER
NO. NO.
W72 8900015150 OPC-911A
1
W73 8900016160 OPC-1691
2
W74 8900016240 OPC-1700
W75 8900016240 OPC-1700
1
W76 8900015150 OPC-911A
1
W77 8900016160 OPC-1691
1
W78 8900016100 OPC-1678
1
W79 8900016390 OPC-1713
1
1
EP1 6910011960 ZCAT1518-0730
1
EP2 6910011960 ZCAT1518-0730
1
EP3 6910011960 ZCAT1518-0730
1
1
MP1 8010020071 2844 CHASSIS-1
1
MP2 8210023981 2844 REAR PANEL (A)-1
1
MP3 8930070470 2844 C-PCB ANGLE
1
MP4 8930070490 2844 CF PLATE
1
MP5 8110008920 2844 LOGIC M-COVER
1
MP6 8110008930 2844 REG S-COVER
1
MP7 8510017050 2844 RF PLATE
1
MP8 8510017040 2844 P-B PLATE
1
MP9 8110008480 2844 L-COVER
1
MP10 8110008471 2844 U-COVER-1
1
MP12 8930070460 2844 RF-B PLATE
1
MP20 8930066500 2844 MAIN PLATE
1
MP21 8510017100 2844 DC-DC COVER
1
MP25 8510017110 2844 SCOPE COVER
1
MP26 8510017030 2844 SCOPE CASE
1
MP27 8930066310 2844 U-FRONT PLATE
1
MP28 8930066300 2844 L-FRONT PLATE
1
MP29 8930067750 2844 SIDE PLATE
1
MP30 8820001371 2844 A-SCREW-1
1
MP31 8820001391 2844 C-SCREW-1
1
MP32 8930067760 2844 RACK ANGLE
MP35 8510011940 2177 PLATE
1
MP36 8930052450 2355 EARTH PLATE
1
MP37 8930049050 2263 ANT PLATE
1
MP38 8930020860 IC-HOLDER
1
MP40 8930066360 2844 SIDE STAND
1
MP41 8930066370 2844 MAIN STAND
1
MP42 8930066340 2844 B-STAND RUBBER
1
MP43 8930066350 2844 A-STAND RUBBER
1
MP44 8110008460 2844 REAR COVER
1
MP45 8930072140 MR PROTECTION CAP
1
MP50 8810008661 Screw BT B0 3X8 NI-ZC3 (BT)
1
MP51 8810008661 Screw BT B0 3X8 NI-ZC3 (BT)
1
MP52 8810008661 Screw BT B0 3X8 NI-ZC3 (BT)
1
MP53 8810008661 Screw BT B0 3X8 NI-ZC3 (BT)
1
MP54 8810008661 Screw BT B0 3X8 NI-ZC3 (BT)
1
MP55 8810008661 Screw BT B0 3X8 NI-ZC3 (BT)
1
MP56 8810008661 Screw BT B0 3X8 NI-ZC3 (BT)
1
MP57 8810008661 Screw BT B0 3X8 NI-ZC3 (BT)
1
MP58 8810008661 Screw BT B0 3X8 NI-ZC3 (BT)
1
MP59 8810008661 Screw BT B0 3X8 NI-ZC3 (BT)
1
MP60 8810008661 Screw BT B0 3X8 NI-ZC3 (BT)
1
MP61 8810008661 Screw BT B0 3X8 NI-ZC3 (BT)
1
MP62 8810008661 Screw BT B0 3X8 NI-ZC3 (BT)
1
MP63 8810008661 Screw BT B0 3X8 NI-ZC3 (BT)
1
MP64 8810008661 Screw BT B0 3X8 NI-ZC3 (BT)
1
MP65 8810009991 Screw BT B0 3X8 NI-ZK3 (BT)
1
MP66 8810009991 Screw BT B0 3X8 NI-ZK3 (BT)
1
MP67 8810009461 Screw M3X8 ZK3
1
MP69 8810007231 Setscrew (H) 3X8 ZC3
1
MP70 8810007231 Setscrew (H) 3X8 ZC3
1
MP71 8810007231 Setscrew (H) 3X8 ZC3
1
MP72 8810005771 Screw BiH M3X8 ZK3
1
MP73 8810005771 Screw BiH M3X8 ZK3
1
MP74 8820001401 2844 D-SCREW-1
1
MP75 8820001401 2844 D-SCREW-1
1
MP76 8810004621 Screw PH M4X8 ZK3
1
MP81 8810007231 Setscrew (H) 3X8 ZC3
1
MP82 8810007231 Setscrew (H) 3X8 ZC3
1
MP83 8810007231 Setscrew (H) 3X8 ZC3
1
MP89 8810007231 Setscrew (H) 3X8 ZC3
1
MP90 8810007231 Setscrew (H) 3X8 ZC3
1
MP91 8810004621 Screw PH M4X8 ZK3
1
MP92 8810009991 Screw BT B0 3X8 NI-ZK3 (BT)
1
MP94 8810005771 Screw BiH M3X8 ZK3
1
MP95 8930071510 2844 RF-B SPRING
1
MP96 8930071680 ANP-1D
1
MP97 8930071690 PJ-13B
1
MP98 8930071700 PJ-21B
1
MP99 8950003640 Coating clip CS-2
1
MP102 8930057311 Shield sponge (I)-1
1
MP104 8930071810 SPONGE (JK)
1
MP105 8930071740 Shield sponge (BQ)
1
MP106 8930071760 Shield sponge (BS)
1
MP107 8930071750 Shield sponge (BR)
1
MP108 8930071730 Shield sponge (BP)
1
MP109 8930071800 FERRITE SHEET (R)
1
6 - 1
