Icom IC-R9500 Service Manual page 85

[CHASSIS PARTS]
REF ORDER
DESCRIPTION
NO. NO.
MP110 8930072090 FERRITE SHEET (S)
MP111 8930057730 Shield sponge (J)
MP112 8930057730 Shield sponge (J)
MP113 8930071550 Shield sponge (BM)
MP114 8930069610 SPONGE (IV)
MP115 8930045920 2056 SPONGE
MP116 8950003640 Coating clip CS-2
MP118 8930063260 SPONGE (HV)
MP119 8810008641 0tap 1fl at washer B0 2X4 NI-ZC3 (BT)
MP120 8930023850 Sheet (AE)
MP121 8950003640 Coating clip CS-2
MP122 8930039870 Sheet (EI)
MP123 8930039870 Sheet (EI)
MP124 8930057730 Shield sponge (J)
MP125 8930057730 Shield sponge (J)
MP126 8930071550 Shield sponge (BM)
MP127 8930063270 2590 EARTH SPRING
MP128 8930071800 FERRITE SHEET (R)
MP129 8930072410 Shield sponge (BW)
MP130 8930072420 Shield sponge (BX)
MP131 8930072430 Shield sponge (BY)
MP132 8930072430 Shield sponge (BY)
MP134 8930029060 Insulation sheet (CT)
MP135 8930043540 Insulation sheet (FA)
MP136 8930072720 Shield sponge (CA)
MP137 8820001400 2844 D-SCREW
MP138 8930072740 HIMELON SHEET (CV)
MP139 8930072750 HIMELON SHEET (CW)
MP140 8930072730 HIMELON SHEET (CU)
MP141 8930072890 Shield sponge (CB)
MP142 8930072890 Shield sponge (CB)
MP143 8930072890 Shield sponge (CB)
MP144 8930072890 Shield sponge (CB)
MP145 8930072890 Shield sponge (CB)
MP146 8930072890 Shield sponge (CB)
MP147 8930071810 SPONGE (JK)
MP6 (CH)
MP1 (ACC)×3
MP4 (F)
MP3 (CH)
MP5 (F)
MP1 (F)
FRONT UNIT
Unit abbreviation (CH) : CHASSIS PARTS
(FR) : FRONT UNIT
QTY.
1
1
1
1
1
1
1
1
4
2
1
1
1
1
1
MP3 (AC)
1
1
1
1
1
1
1
2
1
1
4
2
1 MP50 (CH)×20
2
1
1
1
1
1
1
1
MP120 (CH)
MP5 (CH)
MP27 (CH)
MP28 (CH)
6 - 2
MP2 (CH)
MP10 (CH)
MP41 (CH)×4
MP74 (CH)×4
MP73 (CH)×4
MP118 (CH)
MP1 (CH)
MP5 (F)
MP4 (F)
MP1 (ACC)×3
MP74 (CH)×10
MP44 (CH)
MP2 (CH)
MP134 (CH)
MP8 (CH)
MP3 (AC)
MP50 (CH)×22
MP141 (CH) MP110 (CH)
MP144 (CH)
MP41 (CH)×4
MP9 (CH)
• EXPLODED VIEW (OVERALL)
MP76 (CH)×2
MP50 (CH)×20
MP94 (CH)×2
MP4 (CH)
MP133 (CH)
MP3 (CH)
MP7 (CH) MP134 (CH)
MP109 (CH)
MP143 (CH)
MP142 (CH)
